| 1. |
700109753
|
[1] |
BEARING ASSY,97 mm ID x 108 mm OD x 33 mm
|
CAS
BEARING ASSEMBLY (Includes item 2)
|
| 2. |
712158
|
[1] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
BEARING Superseded by part number: 47577203
|
| 3. |
433-820
|
[8] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 4. |
329-288
|
[8] |
FLANGE NUT,Flg, 1/2"-13, G8
|
CAS
|
| 5. |
413-1036
|
[6] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 X 2-1/4 C Superseded by part number: 88556
|
| 6. |
7704919
|
[6] |
FLANGE NUT,Flg, 5/8"-11, G8
|
CAS
5/8-11 HFN GR8
|
| 7. |
700112817
|
[3] |
SUPPORT
|
CAS
FINGER WA
|
| 8. |
700706850
|
[12] |
SHIM
|
CAS
- 0.51/.020
|
| 9. |
700706133
|
[6] |
SHIM
|
CAS
- 0.25/.010
|
| 10. |
700706134
|
[6] |
SHIM
|
CAS
- 0.13/.005
|
| 11. |
700137305
|
[1] |
CRANK
|
CAS
WA - packer
|
| 12. |
700706131
|
[6] |
BEARING SET,60.15mm ID x 70.12mm OD x 60mm L
|
CAS
BEARING - pair Superseded by part number: 47707444
|
| 13. |
700112787
|
[3] |
FINGER
|
CAS
WA
|
| 14. |
700706096
|
[6] |
SEAL
|
CAS
|
| 15. |
700704263
|
[1] |
SPHERICAL BEARING,55.562 mm ID x 100 mm OD x 48.4 mm
|
CAS
BEARING Superseded by part number: 76451
|
| 16. |
852947
|
[7] |
BUSHING
|
CAS
2-1/4 X 14 GAUGE NRMB
|
| 17. |
700715751
|
[1] |
NUT
|
CAS
- stake
|
| 18. |
700137337
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 80C35
|
| 19. |
700716611
|
[1] |
BEARING ASSY,55.56 mm ID x 111.91 mm OD x 31 mm
|
CAS
BEARING ASSEMBLY - flanged (Includes item 15)
|
| 20. |
700137336
|
[1] |
SPACER
|
CAS
|
| 21. |
433-860
|
[12] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 3 3/4", Gr 5
|
CAS
1/2-13 X 3-3/4 RHSNB Superseded by part number: 280454
|
| 22. |
231-5348
|
[12] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 23. |
700124036
|
[3] |
LINK CONROD
|
CAS
LINK ASSEMBLY - finger (Includes item 25)
|
| 24. |
700124038
|
[12] |
BUSHING,16.27mm ID x 34.92mm OD x 10mm L
|
CAS
- bearing
|
| 25. |
616154R92
|
[6] |
BEARING, ROLLER, CYL,16 mm
|
IH
BEARING Superseded by part number: 84356151
|
