凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (6-08) - TENSION ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
727 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
111-237
|
[2] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5 Superseded by part number: 33-516
|
| 2. |
232-5315
|
[3] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 3. |
413-516
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 5
|
CAS
Superseded by part number: 9635884, 72187198
|
| 4. |
6514772
|
[1] |
SPACER
|
CAS
|
| 5. |
700715941
|
[1] |
FLANGED BEARING
|
CAS
BEARING - flange
|
| 6. |
700137467
|
[1] |
ARM
|
CAS
- right, tension
|
| 7. |
700707700
|
[1] |
BALL BEARING,6.48 mm ID x 31.75 mm OD x 13.08 mm
|
CAS
BEARING Superseded by part number: 700737442
|
| 8. |
700137466
|
[1] |
ARM
|
CAS
- left, tension
|
| 10. |
1703354
|
[2] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 9. |
413-420
|
[2] |
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87716, 72187191
|
