| 1. |
700113311
|
[1] |
FRAME
|
CAS
WA - knotter
|
| 2. |
413-820
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 3. |
495-21056
|
[4] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 4. |
80679
|
[8] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 5. |
425-108
|
[6] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 6. |
433-824
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 X 1-1/2 RHSNB Superseded by part number: 280420, 72187237
|
| 7. |
6845713
|
[1] |
LARGE PLATE
|
CAS
PLATE
|
| 8. |
6845721
|
[1] |
BRACKET
|
CAS
Superseded by part number: 700142093
|
| 9. |
858308
|
[2] |
SPRING
|
CAS
- extension
|
| 10. |
700113336
|
[1] |
ARM
|
CAS
WA - tucker (Includes items 39, 40 and 41)
|
| 11. |
219-17
|
[2] |
LUBE NIPPLE,3/16" NPTF
|
CAS
NIPPLE, LUBE, 3/16" x .55" lg, Drive Superseded by part number: 80722
|
| 12. |
425-118
|
[2] |
NUT,1/2"-20, G5
|
CAS
1/2-20 H Superseded by part number: 280963
|
| 13. |
8050866
|
[2] |
CAM FOLLOWER
|
CAS
BEARING - cam follower Superseded by part number: 84393376
|
| 14. |
495-81205
|
[11] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 18 GAUGE NRMB
|
| 15. |
432-1028
|
[2] |
COTTER PIN,5/32" x 1 3/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 3/4" Superseded by part number: 281075
|
| 16. |
700113330
|
[1] |
SHAFT
|
CAS
WA - finger
|
| 17. |
195-2103
|
[11] |
WASHER,1 1/16" x 1 1/2" x .065"
|
CAS
1 X 18 GAUGE NRMB
|
| 18. |
700113342
|
[2] |
SUPPORT
|
CAS
WA
|
| 19. |
D23692
|
[2] |
SNAP RING,#100, Ext, Crescent
|
CAS
Ring, Snap, #100, Ext, Crescent
|
| 20. |
413-520
|
[10] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 X 1-1/4 C Superseded by part number: 87657
|
| 21. |
495-61034
|
[4] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 22. |
492-11031
|
[10] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 23. |
425-105
|
[10] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 24. |
6844971
|
[1] |
BRACKET
|
CAS
WA
|
| 25. |
700712484
|
[1] |
SPRING
|
CAS
- extension
|
| 26. |
758482
|
[6] |
TENSION SPRING
|
CAS
SPRING - extension
|
| 27. |
6529945
|
[6] |
ROLLER
|
CAS
- needle
|
| 28. |
7849656
|
[6] |
SLEEVE
|
CAS
- roller
|
| 29. |
7849110
|
[6] |
BUSHING,5.23mm ID x 6.99mm OD x 13.49mm L
|
CAS
SLEEVE - bushing
|
| 30. |
363-31016
|
[6] |
SCREW,Hex Wash Hd, #10-24 x 1"
|
CAS
#10-24 X 1 HWHMS
|
| 31. |
492-11010
|
[6] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 32. |
225-14110
|
[6] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 33. |
6523765
|
[6] |
ARM
|
CAS
- tension Superseded by part number: 700150609
|
| 34. |
6523799
|
[10] |
BUSHING
|
CAS
|
| 35. |
700113346
|
[2] |
ROD
|
CAS
WA
|
| 36. |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 37. |
231-5148
|
[4] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 38. |
700714985
|
[1] |
SPRING
|
CAS
- extension
|
| 39. |
164-102
|
[6] |
HEX SOC SCREW,FLAT, #10 - 32 x 1/2"
|
CAS
#10-32 X 1/2 HSFCHCS
|
| 40. |
700707700
|
[6] |
BALL BEARING,6.48 mm ID x 31.75 mm OD x 13.08 mm
|
CAS
BEARING Superseded by part number: 700737442
|
| 41. |
866566
|
[6] |
FASTENER,#10 - 32 x 9/16"
|
CAS
#10-32 FASTENER - special
|
