700113321
|
[1] |
KNOTTER
|
CAS
HEAD ASSEMBLY COMPLETE
|
| 1. |
1712868
|
[1] |
DISC
|
CAS
ASSEMBLY - twine
|
| 2. |
6523807
|
[1] |
CLEANER
|
CAS
- knotter
|
| 3. |
700134430
|
[1] |
STRIPPER
|
CAS
TWINE ASSEMBLY - stripper Superseded by part number: 700138858
|
| 4. |
702400022
|
[1] |
SCREW
|
CAS
5/16-18 SHOULDER SCREW
|
| 5. |
435-7614
|
[3] |
GROOVED PIN,3/16" x 7/8", Type G
|
CAS
Pin, Grooved, 3/16" x 7/8", Type G
|
| 6. |
7894389
|
[1] |
PINION
|
CAS
GEAR - bill hook
|
| 7. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 8. |
413-832
|
[1] |
BOLT,Hex, 1/2" - 13 x 2", Gr 5
|
CAS
Superseded by part number: 9706716
|
| 9. |
219-93
|
[4] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 10. |
6553267
|
[1] |
SHORT SHAFT
|
CAS
SHAFT - knotter, worm
|
| 11. |
702700040
|
[1] |
WORM GEAR
|
CAS
- bevel pinion Superseded by part number: 9838815
|
| 12. |
219-417
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
1/4-28 X 1-5/8 STRAIGHT ZERK Superseded by part number: 571382
|
| 13. |
7852742
|
[1] |
WASHER,19.84mm ID x 27.38mm OD x 0.889mm Thk
|
CAS
25/32 MACHINERY BUSHING - spl
|
| 14. |
100-1175
|
[1] |
SNAP RING,#75, Ext
|
CAS
Ring, Snap, #75, Ext Superseded by part number: 72186587, 129164
|
| 15. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 16. |
700113323
|
[1] |
CAM
|
CAS
- bill hook
|
| 17. |
138-153
|
[1] |
LOCK PIN,5/16" x 1", Slotted
|
CAS
PIN, 5/16" x 1", Slotted Superseded by part number: 88005
|
| 18. |
7895733
|
[1] |
SPRING
|
CAS
TENSIONER - spring Superseded by part number: 9838781
|
| 19. |
231-1445
|
[1] |
NUT,5/16"-18, GB
|
CAS
NUT, LOCK, 5/16"-18, GB Superseded by part number: 86050277
|
| 20. |
6523229
|
[1] |
STUD
|
CAS
- mounting
|
| 21. |
425-146
|
[1] |
JAM NUT,3/8" - 16, Gr 5
|
CAS
3/8-16 HJN GR2 Superseded by part number: 87016560
|
| 22. |
7894454
|
[1] |
PINION
|
CAS
- twine disc
|
| 23. |
6553259
|
[2] |
SPRING
|
CAS
- twine Superseded by part number: 706553259
|
| 24. |
413-616
|
[1] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 25. |
425-116
|
[1] |
NUT,3/8" - 24, Gr 5
|
CAS
Superseded by part number: 86509310, 50066
|
| 26. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 27. |
7894413
|
[1] |
WORM GEAR
|
CAS
WORM - knotter
|
| 28. |
7852163
|
[2] |
BUSHING
|
CAS
5/8 MACHINERY BUSHING - spl
|
| 29. |
6553275
|
[2] |
SHIM
|
CAS
- countershaft
|
| 30. |
700700968
|
[1] |
KNOTTER
|
CAS
BILL AND HOOK ASSEMBLY Superseded by part number: 700734489
|
| 31. |
6591440
|
[1] |
ASSEMBLY
|
CAS
FRAME - knotter head (Includes items 7 and 8) Superseded by part number: 700138857
|
| 32. |
8045148
|
[1] |
HOLDER
|
CAS
- twine
|
