| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 475-6356 | [1] | FRAME AS(RH) | |
| 2. | 475-6357 | [1] | FRAME AS(LH) | |
| 3. | 475-6359 | [1] | CORE AS-AFTERCOOLER | |
| 4. | 475-6360 | [1] | CORE AS-CONDENSER | |
| 484-5529 | [4] | MOUNT AS | ||
| 5. | 475-6361 | [1] | CORE AS-FUEL COOLER | |
| 484-5529 | [4] | MOUNT AS | ||
| 6. | 344-5674M | [8] | NUT(M8X1.25-THD) | |
| 7. | 8T-4189M | [6] | BOLT(M8X1.25X20-MM) | |
| 8. | 8T-4224 | [14] | WASHER-HARD(8.8X16X2-MM THK) | |
| M | METRIC PART | |||
