凯斯零件查询(8585) - CASE IH LARGE (3 X 4) RECTANGLER BALER (1/98-12/00) (6-26) - KNOTTER ARM ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
306 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700137490
|
[1] |
ARM
|
CAS
WA
|
| 2. |
232-53112
|
[1] |
FLANGE NUT,Flg, 3/4"-10
|
CAS
3/4-10 HFTLN GR/G Superseded by part number: 86512372
|
| 3. |
700124056
|
[1] |
ROLLER
|
CAS
- clutch
|
| 4. |
100-1175
|
[2] |
SNAP RING,#75, Ext
|
CAS
Ring, Snap, #75, Ext Superseded by part number: 72186587, 129164
|
| 5. |
6525042
|
[1] |
ROLLER,41.28mm OD x 12.5mm L
|
CAS
- clutch
|
| 6. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 7. |
700137491
|
[1] |
BOLT
|
CAS
- special Superseded by part number: 700137492
|
| 8. |
B18254
|
[1] |
NEEDLE BEARING,Needle, 25.4mm ID x 31.75mm OD x 25.4mm W
|
CAS
BEARING
|
