神钢零件查询(65R5C) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (07-006) - NOZZLE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
861 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-9. | VAME016506 | [6] | NOZZLE ASSY NOZZLE ASSY (N.D.K NO.) (093500-1830) | NOZZLE ASSY NOZZLE ASSY (N.D.K NO.) (093500-1830) |
| 1-9. | VA3136118001 | [1] | NOZZLE ASSY (093500-0831) | |
| 1-8. | VAME016507 | [6] | NOZZLE HOLDER ASSY (093100-1830) | |
| 1-8. | VA3136118101 | [1] | HOLDER ASSY, NOZZLE NOZZLE HOLDER ASSY(093100-0831) | HOLDER ASSY, NOZZLE NOZZLE HOLDER ASSY(093100-0831) |
| 1. | VA9490502480 | [6] | NUT | KOBNUT (N.D.K NO.) |
| 2. | VA0932450110 | [6] | WASHER WASHER | WASHER WASHER |
| 3. | NSS | [6] | NOT SOLD SEPARAT | CONBODY NOZZLE HOLDER(093100-1830) |
| 4. | VA0931750010 | [1] | WASHER t=1.00 | |
| 4. | VA0931750020 | [1] | WASHER t=1.05 (0.05 mm INTERVAL) | |
| 4. | VA0931750190 | [1] | WASHER t=1.90 | |
| 4. | VA0931750200 | [1] | WASHER t=1.95 | |
| 5. | VA0931270020 | [6] | SPRING, PRESSURE | |
| 6. | VA0931210030 | [6] | PIN, PRESSURE | |
| 7. | VA0931740010 | [6] | PIECE, DISTANCE | |
| 8. | VA0931640420 | [6] | NUT NUT RETAINING(N.D.K NO.) | NUT NUT RETAINING(N.D.K NO.) |
| 9. | VAME023682 | [6] | NOZZLE | KOBTIP, NOZZLE N.D.K.NO.(093400-0620) |
| 9. | VAME020996 | [1] | TIP | KOBTIP, NOZZLE N.D.K.NO.(093400-0010) |
