| 1. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 2. |
700717866
|
[1] |
PUMP
|
CAS
- hydraulic Superseded by part number: 700722236
|
| 3. |
218-5064
|
[1] |
HYD CONNECTOR,1-1/16" - 12 Male JIC x 1-1/16" - 12 Male ORB
|
CAS
(Incl. Item 6) 1 1/16"-12, 37º x 1 1/16"-12, O-Ring Superseded by part number: 322896, 72186119
|
| 4. |
218-5060
|
[1] |
HYD CONNECTOR,3/4" - 16 Male JIC x 7/8" - 14 Male ORB
|
CAS
Fitting (Incl. Item 5) 3/4"-16, 37º x 7/8"-14, O-Ring Superseded by part number: 128819
|
| 5. |
237-6010
|
[1] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
10-1, 90 Duro, .755" ID x .097" Thk Superseded by part number: 72186125, 167269
|
| 6. |
738484
|
[1] |
O-RING
|
IH
Superseded by part number: 167266
|
| 7. |
121-226
|
[12] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 8. |
329-286
|
[16] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 9. |
700149701
|
[1] |
SHIELD
|
HFI
- flywheel
|
| 10. |
700149702
|
[2] |
SUPPORT
|
HFI
ANGLE - support
|
| 11. |
700149700
|
[1] |
SUPPORT
|
HFI
- angle
|
| 12. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 13. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 14. |
700718483
|
[1] |
SHIM
|
CAS
- .018
|
| 15. |
700718484
|
[6] |
SHIM
|
CAS
- .034
|
| 16. |
700149737
|
[1] |
ANGLE
|
HFI
WA - mounting, pump
|
| 17. |
873513
|
[1] |
BOLT,Hex, 1/2" - 13 x 6", Gr 5, Full Thd
|
IH
1/2-13 X 6 FTC Superseded by part number: 86000020
|
| 18. |
425-148
|
[1] |
JAM NUT,Jam, 1/2"-13, G5
|
CAS
Superseded by part number: 86632558
|
| 19. |
700149726
|
[1] |
SUPPORT
|
HFI
WA - pump
|
| 20. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 X 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 21. |
700149735
|
[1] |
SHEAVE
|
HFI
- HA
|
| 22. |
83-1256
|
[2] |
SET SCREW,Hex Soc, 1/4"-20 x 3/8"
|
CAS
1/4-20 X 3/8 CPHSSS NP
|
| 23. |
700718206
|
[1] |
V-BELT,1828.80 mm L
|
CAS
|
| 24. |
700149736
|
[1] |
SHEAVE
|
HFI
- HA
|
| 25. |
413-824
|
[3] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 26. |
80679
|
[3] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
