凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (02-32) - BEARING ASSEMBLY, S.N. CFH0139090 AND LATER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
513 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700716382
|
[1] |
SEAL
|
CAS
- oil
|
| 2. |
700129488
|
[1] |
SPACER
|
HFI
- bushing, seal
|
| 3. |
700129487
|
[1] |
BEARING HOUSING
|
HFI
HOUSING - bearing, crankarm
|
| 4. |
700716384
|
[1] |
SPHERICAL BEARING,75 mm ID x 160 mm OD x 55 mm
|
CAS
BEARING - spherical roller Superseded by part number: 700138991, 700724470
|
| 5. |
8052144
|
[1] |
RING, SNAP
|
CAS
RING - retaining
|
| 6. |
700129489
|
[1] |
BUSHING
|
HFI
- seal
|
| 7. |
700716383
|
[1] |
SEAL
|
CAS
- oil
|
