神钢零件查询(65R5P) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (01-001) - CYLINDER HEAD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
375 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-14. | VAME999066 | [1] | CYLINDER HEAD | KOBCYLINDER HEAD ASSY |
| 1-14. | VA3170111020 | [2] | CYLINDER HEAD ASSY | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHEAD, CYLINDER (ME001129) |
| 2. | VA3160111600 | [6] | VALVE GUIDE | KOBGUIDE, VALVE, INLET |
| 2. | VA3130110601 | [6] | GUIDE, VALVE, INLET | |
| 2A. | VAME001083 | [6] | GUIDE GUIDE, VALVE, EXHAUST | GUIDE GUIDE, VALVE, EXHAUST |
| 2A. | VA3160111600 | [6] | VALVE GUIDE | KOBGUIDE, VALVE, EXHAUST |
| 2A. | VA3130110601 | [6] | GUIDE, VALVE, EXHAUST | |
| 3. | VAMF407006 | [6] | SCREW | KOBSTUD, EXH, MANIFOLD 10X25 |
| 3. | VAMH004054 | [6] | NUT | KOBNUT 10 Superseded by part number: 134868A1 |
| 4. | VAMH002105 | [11] | STUD STUD, WATER OUTLET PIPE 8X40 | STUD STUD, WATER OUTLET PIPE 8X40 |
| 4. | VAMF434104 | [12] | NUT | KOBNUT, FLANGE 8 |
| 4. | VAMF430005 | [1] | NUT | KOBNUT 8 Superseded by part number: VAF230008000 |
| 4. | VAMF450405 | [12] | WASHER | KOBWASHER, SPRING 8 Superseded by part number: 132502A1 |
| 4A. | VAMH002106 | [1] | STUD | KOBSTUD, WATER OUTLET PIPE 8X70 (31701—19101) |
| 5. | VAMS666137 | [6] | CAP | KOBCAP, SEALING D=25 |
| 6. | VAMS666140 | [3] | PLUG | KOBCAP SEALING D=35 |
| 7. | VAMS666139 | [5] | CAP | KOBCAP, SEALING D=30 |
| 8. | VAMS666136 | [2] | PLUG | KOBCAP SEALING D=22 |
| 9. | VA3130101202 | [7] | DIRECTOR | |
| 10. | VAME001080 | [5] | JET | KOBJET COMBUSTION CHAMBER, STD |
| 10. | VA3160300101 | [5] | JET COMBUSTION CHAMBER, STD | |
| 10. | VAME001081 | [1] | O.S. 0.03 | |
| 10. | VA3160300201 | [1] | O.S. 0.03 | |
| 11. | VAME001074 | [6] | INSERT INSERT VALVE SEAT,EXH. | INSERT INSERT VALVE SEAT,EXH. |
