凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (03-14) - PICKUP CLUTCH ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
842 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700113260
|
[1] |
SHAFT
|
CAS
|
| 2. |
51292
|
[1] |
SPHERICAL BEARING,1.25" ID x 72 mm OD x 19 mm
|
IH
- spherical Superseded by part number: 84330041, 47508357
|
| 3. |
617863R1
|
[1] |
FLANGED BEARING
|
IH
- bearing
|
| 4. |
495-81205
|
[4] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 X 18 GAUGE NRMB
|
| 5. |
6564983
|
[1] |
BUSHING
|
CAS
|
| 6. |
6564975
|
[1] |
BRONZE BUSHING,57.3mm ID x 66.79mm OD x 19.13mm L
|
CAS
BEARING - bronze
|
| 7. |
126-133
|
[1] |
WOODRUFF KEY,#D, 5/16" x 1 1/4", HT
|
CAS
Superseded by part number: 87831
|
| 8. |
6549588
|
[1] |
SPACER
|
CAS
|
| 9. |
700711025
|
[2] |
CLUTCH PLATE,92mm ID x 161.92mm OD x 3.18mm Thk
|
CAS
DISC - friction
|
| 10. |
700113257
|
[1] |
CLUTCH PLATE
|
CAS
PLATE - clutch
|
| 11. |
37-1820
|
[2] |
DOWEL,1/2" x 1 1/4"
|
CAS
1/2 X 1-1/4 DOWEL PIN Superseded by part number: 81848
|
| 12. |
58511
|
[4] |
COMPRESSION SPRING
|
IH
SPRING - compression
|
| 13. |
38-12036
|
[1] |
LOCK PIN,5/16" x 2 1/4", Slotted
|
CAS
Pin, 5/16" x 2 1/4", Slotted Superseded by part number: 87019504
|
| 14. |
6522668
|
[1] |
HUB
|
CAS
- clutch
|
| 15. |
231-1406
|
[8] |
LOCK NUT,3/8"-16, GB
|
CAS
3/8-16 LHSN
|
| 16. |
495-21044
|
[8] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 17. |
58107
|
[8] |
SPRING
|
IH
- compression
|
| 18. |
700113259
|
[1] |
CLUTCH
|
CAS
ASSEMBLY (Includes Item 5)
|
| 19. |
700113254
|
[1] |
SPROCKET,43T
|
CAS
ASSEMBLY 50A43 TOOTH (Includes Item 6)
|
| 20. |
433-656
|
[8] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3 1/2", Gr 5
|
CAS
3/8-16 X 3-1/2 RHSNB Superseded by part number: 280348
|
