凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (03-18) - BAR ASSEMBLY, TINE, S.N. CFH0139001 THRU CFH0139499 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
459 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
431-1632
|
[10] |
1/4 X 2 COTTER PIN
|
|
| 2. |
700714199
|
[60] |
TINE
|
CAS
- double Superseded by part number: 84162978
|
| 3. |
702700045
|
[5] |
LOCK NUT
|
L
- spiralock
|
| 4. |
80679
|
[5] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 5. |
700705612
|
[5] |
CAM FOLLOWER
|
L
BEARING - cam, follower Superseded by part number: 86536275
|
| 6. |
700113239
|
[5] |
CRANK
|
CAS
WA
|
| 7. |
700108622
|
[10] |
FLANGED BEARING
|
L
FLANGE - bearing
|
| 8. |
710392
|
[10] |
BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm
|
L
BEARING - cylindrical Superseded by part number: 84330047
|
| 9. |
61-33832
|
[5] |
HEX SOC SCREW,3/8 - 16 x 2"
|
CAS
3/8-16 X 2 HSHCS
|
| 10. |
496-11041
|
[60] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 11. |
232-5316
|
[60] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 12. |
434-616
|
[55] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 13. |
700113235
|
[5] |
CHANNEL
|
CAS
- tine
|
