神钢零件查询(65R5P) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (02-005) - TIMING GEAR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
433 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONTIMING GEAR |
| 1. | VA3132310101 | [1] | GEAR, CRANKSHAFT Z=20 | |
| 2. | VA3132311102 | [1] | GEAR | KOBGEAR, CAMSHAFT Z=40 |
| 3. | VAMH005020 | [1] | PLATE | KOBWASHER, Start Year: 01-DEC-79 |
| 3. | VA3162301900 | [1] | WASHER | |
| 4. | VA3162301600 | [1] | WASHER, LOCK, Years: -01-NOV-79 | |
| 5. | VAMF472551 | [1] | PIN, SPRING 4X14, Years: -01-NOV-79 | |
| 6. | VAMH000358 | [1] | BOLT BOLT 10X22, Start Year: 01-DEC-79 | BOLT BOLT 10X22, Start Year: 01-DEC-79 |
| 6. | VAMF138114 | [1] | BOLT 10X20 | |
| 7-8. | VA3132313010 | [1] | RING GEAR | KOBIDLER GEAR ASSY (31323-13100) |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, IDLER 2=45 |
| 8. | VAME020488 | [1] | BUSHING | KOBBUSHING, IDLER |
| 9-10. | VA3162302100 | [1] | SHAFT | KOBIDLER SHAFT ASSY |
| 9. | VA3132313500 | [1] | SHAFT,IDLER SHAFT, IDLER | SHAFT,IDLER SHAFT, IDLER |
| 10. | VAMF472569 | [1] | PIN, SPRING 5X16 | |
| 11. | VAME020491 | [1] | PLATE PLATE, THRUST | PLATE PLATE, THRUST |
| 12. | VA3162303701 | [1] | WASHER | KOBWASHER |
| 13. | VAMF101282 | [1] | BOLT BOLT 10X18 | BOLT BOLT 10X18 |
| 14-17. | VAME008303 | [1] | INJECTION PUMP GEAR ASSY (FOR M0 ONLY), Start Year: 01-JAN-80 | |
| 14-17. | VA3176181030 | [1] | INJECTION PUMP GEAR ASSY | |
| 14. | VAME008304 | [1] | GEAR, INJECTION PUMP Z=40 (FOR M0 ONLY), Start Year: 01-JAN-80 | |
| 14. | VA3132312100 | [1] | GEAR, INJECTION PUMP Z=40 | |
| 15. | VA3132302703 | [1] | PLATE, GUIDE, Years: -01-DEC-79 | |
| 16. | VA3176114100 | [1] | COUPLING (FOR M0 ONLY) | |
| 17. | VAMF241227 | [6] | BOLT | KOBBOLT W/WASHER 6X20 (FOR M0 ONLY) |
| 18. | VA3176110600 | [1] | AUTOMATIC TIMER ASSY (FOR M1 )SEE. FIG. 02-006, Start Year: 01-MAR-81 | |
| 18. | VAME008301 | [1] | AUTOMATIC TIMER ASSY, Start Year: 01-JAN-80 | |
| 18. | VA3176180020 | [1] | AUTOMATIC TIMER ASSY | |
