凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (04-04) - LIGHTS ASSEMBLY, TAIL AND FLASHER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
677 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700706634
|
[1] |
STOP LIGHT
|
IH
LIGHT - tail (Red)
|
| 2. |
515-2395
|
[6] |
CLAMP,3/8", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86572009
|
| 3. |
700708036
|
[2] |
SIDE LAMP ASSY
|
IH
LIGHT - flasher (Yellow) (Includes Item 13) Superseded by part number: 130609
|
| 4. |
515-25127
|
[3] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Superseded by part number: 86632595
|
| 5. |
492-11038
|
[7] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 6. |
425-106
|
[7] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 7. |
700706642
|
[1] |
WIRE HARNESS
|
CAS
HARNESS - wire
|
| 8. |
L18337
|
[1] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
| 9. |
433-512
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 10. |
496-21034
|
[2] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 11. |
492-11031
|
[2] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 12. |
425-105
|
[2] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 13. |
700711749
|
[4] |
LENS
|
CAS
(Yellow) Superseded by part number: 71193862
|
| 14. |
413-612
|
[5] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
