| 1. |
515-25127
|
[8] |
CLAMP,1/2", Insul, 1/2" Bolt
|
CAS
Line 1/2", Insul, 1/2" Bolt Superseded by part number: 86632595
|
| 2. |
432-1020
|
[6] |
COTTER PIN,5/32" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 5/32" x 1 1/4" Superseded by part number: 86523851
|
| 3. |
700119558
|
[2] |
PIN
|
CAS
|
| 4. |
7075625
|
[2] |
CYLINDER
|
L
ASSEMBLY - hydraulic Superseded by part number: 700726495
|
| 5. |
439-11032
|
[2] |
HEADED PIN,15.88mm OD x 50.8mm L
|
CAS
5/8 X 2 CLEVIS PIN
|
| 6. |
218-533
|
[4] |
ELBOW,45 Degree, 9/16-18" 37 Degree x 1/4"-18, NPTF
|
CAS
Superseded by part number: 9617966
|
| 7. |
111-237
|
[6] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5 Superseded by part number: 33-516
|
| 8. |
496-21034
|
[11] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 9. |
231-5145
|
[11] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 10. |
700715832
|
[2] |
TUBE ASSY.,9.52 mm OD, 90, 90 mm Length
|
CAS
LINE - hydraulic
|
| 11. |
700708939
|
[10] |
CLAMP
|
CAS
- heavy, duty
|
| 12. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 13. |
413-652
|
[2] |
BOLT,Hex, 3/8" - 16 x 3-1/4", Gr 5
|
CAS
Superseded by part number: 9637240
|
| 14. |
700715831
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 15. |
738468
|
[1] |
O-RING
|
IH
|
| 16. |
121-108
|
[5] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 17. |
700706387
|
[1] |
CONTROL VALVE
|
CAS
VALVE ASSEMBLY - control Superseded by part number: 700709986
|
| 18. |
237-6010
|
[2] |
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
|
CAS
10-1, 90 Duro, .755" ID x .097" Thk Superseded by part number: 72186125, 167269
|
| 19. |
218-5065
|
[1] |
HYD CONNECTOR,1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB
|
CAS
CONNECTOR, HYD., (Includes Item 18) 1 1/16"-12, 37º x 7/8"-14, O-Ring Superseded by part number: 72187020, 144124
|
| 20. |
218-5231
|
[1] |
ELBOW,90 Degree, 1 1/16"-12, 37 Degree x 1 1/16"-12, 37 Degree Fem Sw
|
CAS
Superseded by part number: 72186121, 219603
|
| 21. |
218-5123
|
[1] |
ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB
|
CAS
90 DEGREE ELBOW (Includes Item 18) Superseded by part number: 144123
|
| 22. |
700706391
|
[1] |
FLEXIBLE HOSE
|
CAS
LINE - hydraulic
|
| 23. |
218-5057
|
[1] |
HYD CONNECTOR,9/16" - 18 JIC x 9/16" - 18 ORB
|
CAS
CONNECTOR (Incl. Item 15) Superseded by part number: 76350
|
| 24. |
218-5222
|
[2] |
TEE,37 Degree, 9/16"-18, x 9/16"-18, Fem Sw Run
|
CAS
Superseded by part number: 72186135, 129274
|
| 25. |
700716376
|
[2] |
FLEXIBLE HOSE
|
CAS
LINE - hydraulic
|
| 26. |
700716463
|
[4] |
FLEXIBLE HOSE
|
CAS
HOSE - hydraulic
|
