凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (08-08) - HYDRAULIC CYLINDER ASSEMBLY, PICKUP, 7075625 HYDRAULIC CYLINDER COMPLETE, 2" BORE X 4" STROKE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
979 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7075625
|
[1] |
CYLINDER
|
L
HYDRAULIC CYLINDER COMPLETE (2 Inch Bore x 4 Inch Stroke) Superseded by part number: 700726495
|
| 2. |
7732258
|
[1] |
TUBE ASSY.
|
CAS
BARREL
|
| 3. |
7732266
|
[1] |
ROD
|
CAS
PISTON ROD ASSEMBLY
|
| 4. |
7732241
|
[1] |
HEAD
|
CAS
- cylinder
|
| 5. |
7732274
|
[1] |
SEAL KIT
|
L
SEAL KIT Superseded by part number: 272468
|
