神钢零件查询(65R5P) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (05-005) - OIL FILTER P/N VAME004090 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
369 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-11. | VAME004090 | [1] | FILTER | KOBOIL FILTER ASSY (FOR M0 ONLY), Start Serial: 8103- |
| 1-11. | VA3174000011 | [1] | FILTER OIL FILTER ASSY | FILTER OIL FILTER ASSY |
| 1-3. | VA3144012030 | [1] | ELEMENT KIT OIL FILT OIL FILTER ELEMENT KIT (FOR M0 ONLY) | ELEMENT KIT OIL FILT OIL FILTER ELEMENT KIT (FOR M0 ONLY) |
| 1. | VA3134011700 | [1] | O-RING O-RING, CENTER BOLT (FOR M0 ONLY) | O-RING O-RING, CENTER BOLT (FOR M0 ONLY) |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONELEMENT OIL FILTER, (31440—12200), (FOR M0 ONLY) |
| 3. | VA3134012600 | [1] | O-RING | KOBGASKET OIL FILTER (FOR M0 ONLY) |
| 4. | VA3134011040 | [1] | SPRING | KOBSPRING ASSY (FOR M0 ONLY) |
| 5. | VA3144012708 | [1] | BOLT | KOBBOLT CENTER (FOR M0 ONLY) |
| 6-8. | VA3144013603 | [1] | COVER | KOBOIL FILTER CASE ASSY (FOR M0 ONLY) |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, OIL FILTER (FOR M0 ONLY) |
| 7. | VA3134014700 | [1] | PLUG DRAIN PLUG, DRAIN (FOR M0 ONLY) | PLUG DRAIN PLUG, DRAIN (FOR M0 ONLY) |
| 8. | VAMF660034 | [1] | SEAL | KOBGASKET 12 (FOR M0 ONLY) |
| 9. | VA3134021904 | [1] | CYLINDER HEAD | KOBHEAD, OIL FILTER (FOR M0 ONLY) |
| 10. | VA3134014500 | [1] | GASKET | KOBGASKET (FOR M0 ONLY) |
| 11. | VAME014810 | [1] | HYDRAULIC VALVE | KOBRELIEF VALVE ASSY |
| 11. | VA3134013021 | [1] | RELIEF VALVE ASSY, Start Serial: 8103- | |
| 17. | VAMF302527 | [3] | BOLT BOLT W/WASHER 10X35 (FOR M0 ONLY) | BOLT BOLT W/WASHER 10X35 (FOR M0 ONLY) |
| 19. | VA3134001102 | [1] | ARARM ALARM, OIL BY-PASS (FOR M0 ONLY) | ARARM ALARM, OIL BY-PASS (FOR M0 ONLY) |
| 20. | VAMF660066 | [1] | GASKET | KOBGASKET 16 (FOR M0 ONLY) Superseded by part number: VAF420216000 |
| 21. | VA3134003102 | [1] | GASKET | KOBGASKET |
