沃尔沃零件查询MD40A; TMD40A; TMD40B; TMD40C; AQD40A; TAMD40A; TAMD40B; AD40B; AQAD40A; AQAD40BFuel SystemSmoke EliminatorEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
735 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
|
|
|
|
| 2. |
244416
|
[1] |
Housing
|
|
| 3. |
|
|
|
|
| 4. |
244418
|
[1] |
Gasket
|
|
| 5. |
|
|
|
|
| 6. |
244417
|
[1] |
O-ring
|
|
| 7. |
|
|
|
|
| 8. |
|
|
|
|
| 9. |
|
|
|
|
| 10. |
|
|
|
|
| 11. |
|
|
|
|
| 12. |
244421
|
[1] |
Bushing
|
TH=2,7mm
|
| 12. |
244422
|
[1] |
Bushing
|
TH=3,5mm
|
| 12. |
244423
|
[1] |
Bushing
|
TH=4,3mm
|
| 13. |
244420
|
[1] |
Spring
|
|
| 14. |
|
|
|
|
| 15. |
|
|
|
|
| 16. |
244419
|
[1] |
Diaphragm
|
|
| 17. |
941906
|
[1] |
Spring washer
|
|
| 18. |
955781
|
[1] |
Hexagon nut
|
(244116)
|
| 19. |
|
|
|
|
| 20. |
|
|
|
|
| 21. |
|
|
|
|
| 22. |
956092
|
[2] |
Cross recessed screw
|
|
| 23. |
844235
|
[1] |
O-ring
|
|
| 24. |
|
|
|
|
| 25. |
955892
|
[1] |
Washer
|
|
| 26. |
955781
|
[1] |
Hexagon nut
|
(238426)
|
| 27. |
844223
|
[1] |
Spring
|
|
| 28. |
|
|
|
|
| 29. |
|
|
|
|
| 30. |
|
|
|
|
| 31. |
|
|
|
|
| 32. |
|
|
|
|
| 33. |
941906
|
[1] |
Spring washer
|
(955919)
|
| 34. |
955781
|
[1] |
Hexagon nut
|
|
| 35. |
|
|
|
|
| 36. |
|
|
|
|
| 37. |
|
|
|
|
| 38. |
25703
|
[1] |
Washer
|
|
| 39. |
|
|
|
|
| 40. |
955781
|
[2] |
Hexagon nut
|
|
| 41. |
|
|
|
|
| 42. |
|
|
|
|
| 42A. |
955781
|
[1] |
Hexagon nut
|
|
| 42B. |
|
|
|
|
| 43. |
18839
|
[2] |
Gasket
|
|
| 44. |
|
|
|
|
| 45. |
|
|
|
|
| 46. |
|
|
|
|
| 47. |
|
|
|
|
| 48. |
|
|
|
|
| 49. |
844237
|
[1] |
Hollow screw
|
|
| 50. |
|
|
|
|
| 51. |
|
|
|
|
| 52. |
|
|
|
|
| 53. |
|
|
|
|
| 54. |
190990
|
[1] |
Gasket
|
|
| 55. |
|
|
|
|
| 56. |
|
|
|
|
| 57. |
190990
|
[1] |
Gasket
|
|
| 58. |
|
|
|
|
| 59. |
844189
|
[1] |
Screw
|
|
| 60. |
|
|
|
|
| 61. |
844190
|
[1] |
Tension spring
|
|
| 62. |
18836
|
[1] |
Gasket
|
|
| 63. |
837735
|
[1] |
Plug
|
|
| 64. |
|
|
|
|
| 65. |
941906
|
[1] |
Spring washer
|
(955919)
|
| 66. |
|
|
|
|
| 67. |
|
|
|
|
| 68. |
844230
|
[1] |
Spring
|
|
| 69. |
|
|
|
Alt
|
| 70. |
|
|
|
|
| 71. |
941906
|
[1] |
Spring washer
|
(955919)
|
| 72. |
955781
|
[1] |
Hexagon nut
|
|
| 73. |
|
|
|
|
| 73. |
844240
|
[1] |
Gasket kit
|
|
