凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (06-16) - DRIVE CLUTCH ASSEMBLY, KNOTTER CAM Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
592 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700134414
|
[1] |
ARM
|
HFI
WA - clutch
|
| 2. |
700710414
|
[2] |
JAM NUT
|
CAS
1/2-13 HJN GR8 NP
|
| 3. |
708081
|
[2] |
SET SCREW,Sq Hd, 1/2"-13 x 1 1/4"
|
CAS
1/2-13 X 1-1/4 CPSQHSS NP
|
| 4. |
61879
|
[1] |
KEY
|
CAS
1/2 X 1/2 X 2-1/2 KEY
|
| 5. |
6523534
|
[3] |
SHIM
|
CAS
|
| 6. |
101-11215
|
[1] |
SNAP RING,#215, 2.026", Ext
|
CAS
RING, SNAP, , Retaining #215, 2.026", Ext
|
| 7. |
219-1
|
[1] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
1/8-27 STR ZERK Superseded by part number: 80710
|
| 8. |
6524623
|
[1] |
ROLLER,41.28mm OD x 18.67mm L
|
CAS
|
| 9. |
6524649
|
[1] |
PIN
|
CAS
SHAFT - clutch
|
| 10. |
135-358
|
[1] |
GROOVED PIN,1/4" x 1 1/4", Type F
|
CAS
Pin, Grooved, 1/4" x 1 1/4", Type F
|
| 11. |
219-90
|
[1] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
1/4-28 X 45 DEGREE ZERK Superseded by part number: 87569
|
| 12. |
758268
|
[1] |
SPRING
|
CAS
- extension
|
| 13. |
700124052
|
[1] |
ARM
|
CAS
ASSEMBLY - clutch (Includes Items 8, 9, 10 and 11)
|
| 14. |
6523500
|
[3] |
WASHER
|
CAS
BUSHING
|
| 15. |
6523518
|
[1] |
SHAFT
|
CAS
- clutch
|
| 16. |
178-244
|
[1] |
SET SCREW,Hex Soc, 5/16"-18 x 3/4"
|
CAS
5/16-18 X 3/4 HDPHSSS Superseded by part number: 80432
|
| 17. |
700137486
|
[1] |
SPROCKET,40T
|
CAS
- cam (Includes Item 18)
|
| 18. |
700122883
|
[2] |
BRONZE BUSHING
|
CAS
BEARING - bronze
|
