神钢零件查询(65R5P) - MITSUBISHI DIESEL ENGINE - LK300A WHEEL LOADER (1/06-12/06) (14-012) - TRANSMISSION GEAR SHIFTER UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
565 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME600459 | [1] | CASE, GEAR SHIFT UPPER, Start Serial: 8012 | |
| 1. | VA4401650100 | [1] | CASE, GEAR SHIFT UPPER, SERVICE PART EXCLUSIVELY FOR INDUSTRIAL MACHINERY ENGINES, Start Serial: 7904 | |
| 1. | VA4401640100 | [1] | CASE, GEAR SHIFT UPPER | |
| 2-9. | VA4401651010 | [1] | GEAR SHIFT LEVER ASSY | |
| 2. | VA4401651301 | [1] | LEVER, GEAR SHIFT, Start Serial: 7904 | |
| 2. | VA4401647600 | [1] | LEVER, GEAR SHIFT | |
| 3. | VA4441631601 | [1] | KNOB, GEAR SHIFT LEVER | |
| 4. | VAMF430727 | [1] | NUT NUT JAM 12 | NUT NUT JAM 12 |
| 5. | VA4401622100 | [1] | COVER, FULCRUM | |
| 6. | VA4401622300 | [1] | SPRING, FULCRUM | |
| 7. | VA4401622600 | [1] | RETAINER, FULCRUM SPRING | |
| 8. | VA4401622700 | [1] | STOPPER | |
| 9. | VA4401622800 | [1] | COVER, DUST | |
| 10. | VA4401620500 | [1] | PIN, DOWEL | |
| 11. | VAME600127 | [1] | BREATHER, AIR, Start Serial: 7904 | |
| 11. | VA0334925000 | [1] | BREATHER, AIR | |
| 12. | VA4401659100 | [1] | GASKET GEAR SHIFT UPPER, Serial Range: 7904-8001 | |
| 12. | VA4401629200 | [1] | GASKET GEAR SHIFT UPPER | |
| 13. | VAMF241259 | [4] | BOLT | KOBBOLT, W/WASHER 8X35 |
