凯斯零件查询(8590) - CASE IH LARGE RECTANGULAR BALER (EUROPE) (1/97-12/98) (2-12) - GEARBOX MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
548 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700122647
|
[1] |
PIN
|
CAS
|
| 2. |
700706062
|
[3] |
SHIM
|
CAS
- 0.08 x .003
|
| 3. |
700706063
|
[6] |
SHIM
|
CAS
- 0.13 x .005
|
| 4. |
700706064
|
[6] |
SHIM
|
CAS
- 0.25 x .010
|
| 5. |
700113042
|
[4] |
SPACER
|
CAS
|
| 6. |
413-1264
|
[4] |
BOLT,Hex, 3/4" - 10 x 4", Gr 5
|
CAS
3/4-10 X 4 C Superseded by part number: 280210
|
| 7. |
230-41112
|
[4] |
LOCK NUT,3/4"-10, GA
|
CAS
3/4-10 HTLN GR/B Superseded by part number: 280375
|
| 8. |
700715980
|
[1] |
GEARBOX
|
CAS
ASSEMBLY Superseded by part number: 700716952, 700722210
|
| 9. |
7771504
|
[2] |
BOLT
|
CAS
5/8-11 X 3 FTCS
|
| 10. |
425-1010
|
[4] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 11. |
700122653
|
[6] |
SHIM
|
CAS
|
| 12. |
700122654
|
[4] |
SHIM
|
CAS
|
| 13. |
700122646
|
[1] |
TUBE,38.1 mm OD, 278 mm Length
|
CAS
|
| 14. |
700113047
|
[2] |
PIN
|
CAS
WA
|
| 15. |
700122650
|
[1] |
PIN
|
CAS
|
| 16. |
326-1672
|
[2] |
BOLT,Hex, 1" - 8 x 4-1/2", Gr 8
|
CAS
|
| 17. |
232-41116
|
[2] |
LOCK NUT,1"-8, GC
|
CAS
NUT, LOCK, 1"-8, GC Superseded by part number: 9626600
|
