凯斯零件查询(8590) - CASE IH LARGE RECTANGULAR BALER (EUROPE) (1/97-12/98) (2-18) - GEARBOX ASSEMBLY, (CON'T) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
948 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700706045
|
[2] |
SEAL
|
CAS
LIP - seal, input
|
| 2. |
7771926
|
[12] |
SPECIAL BOLT
|
CAS
M12 X 1.75 X 45 C Superseded by part number: 9628065
|
| 3. |
700715985
|
[1] |
SEAL
|
CAS
- input, carrier
|
| 4. |
700720024
|
[1] |
O-RING
|
CAS
|
| 5. |
700706065
|
[1] |
NUT
|
CAS
STAKE - nut
|
| 6. |
700706032
|
[1] |
WASHER
|
CAS
- keyed
|
| 7. |
700706030
|
[1] |
ROLLER BEARING,76.2mm ID x 48.26mm W
|
CAS
CONE - bearing
|
| 8. |
700706034
|
[2] |
BEARING CUP,161.93mm OD x 38.1mm W
|
CAS
CUP - bearing
|
| 9. |
700715983
|
[1] |
CARRIER FLANGE SEAL
|
CAS
CARRIER - bearing, input
|
| 10. |
700720023
|
[1] |
O-RING
|
CAS
|
| 11. |
700706029
|
[1] |
BEARING CUP
|
CAS
CUP - bearing Superseded by part number: CASA140553
|
| 12. |
700706027
|
[1] |
ROLLER BEARING,84.138 mm ID x 46.038 mm
|
CAS
CONE - bearing
|
| 13. |
700706088
|
[1] |
BEVEL GEAR
|
CAS
PINION - bevel & ring-gear
|
| 14. |
700715991
|
[1] |
SHIM KIT
|
CAS
PACK - shim, carrier
|
| 15. |
700715982
|
[1] |
PLATE
|
CAS
CARRIER - bearing, seal
|
| 16. |
700717687
|
[1] |
SEAL
|
CAS
LIP - seal Superseded by part number: 276013
|
| 17. |
700717685
|
[18] |
SCREW
|
CAS
M12 X 1.75 X 35 HSHCS SPL Superseded by part number: 863-12035
|
| 18. |
700717688
|
[1] |
O-RING
|
CAS
|
| 19. |
700715992
|
[1] |
SHIM KIT
|
CAS
PACK - shim
|
| 20. |
ST807
|
[1] |
BEARING CUP,122.24mm OD x 36.51mm W
|
IH
CUP - bearing
|
| 21. |
700706035
|
[1] |
ROLLER BEARING,63.5 mm ID x 43.764 mm
|
CAS
CONE - bearing
|
| 22. |
700708353
|
[12] |
SCREW
|
HFI
M12 X 1.75 X 40 C
|
| 23. |
700706089
|
[1] |
PINION
|
CAS
SHAFT - spur, input
|
| 24. |
700113013
|
[1] |
CAP
|
CAS
BEARING - cap, input
|
| 25. |
700706033
|
[1] |
ROLLER BEARING,88.9 mm ID x 48.26 mm
|
CAS
CONE - bearing
|
| 26. |
700706070
|
[3] |
SHIM
|
CAS
- left, inter 0.08/.003
|
| 27. |
700706071
|
[2] |
SHIM
|
CAS
- left, inter 0.13/.005
|
| 28. |
700706072
|
[2] |
SHIM
|
CAS
- left, inter 0.25/.010
|
| 29. |
700706073
|
[2] |
SHIM
|
CAS
- left, inter 0.51/.020
|
