| 1. |
700714529
|
[2] |
SOCKET/RECEPTACLE
|
CAS
RECEPTACLE Superseded by part number: 292504A1
|
| 2. |
700133681
|
[2] |
SUPPORT
|
HFI
|
| 3. |
340-1108
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
10-24 X 1/2 CRPHMS GR 60M
|
| 4. |
195-513
|
[4] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 5. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 6. |
225-14110
|
[4] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 7. |
700108658
|
[4] |
SUPPORT
|
CAS
- hinge Superseded by part number: 700163299
|
| 8. |
317818
|
[1] |
PIN
|
CAS
HINGE - pin Superseded by part number: 700317818
|
| 9. |
700114002
|
[1] |
CHANNEL
|
CAS
- left
|
| 10. |
700133682
|
[1] |
SHIELD
|
HFI
- front, left Superseded by part number: 700138238
|
| 11. |
700133679
|
[1] |
SHIELD
|
HFI
- left
|
| 12. |
700714528
|
[2] |
LATCH
|
CAS
- 1/4 turn Superseded by part number: 292505A1
|
| 13. |
700114000
|
[1] |
SHIELD
|
CAS
- left Superseded by part number: 700150652
|
| 14. |
256873
|
[20] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 15. |
231-5145
|
[32] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 16. |
413-824
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 17. |
231-5348
|
[4] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 18. |
495-21056
|
[8] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 19. |
433-512
|
[10] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 20. |
496-21034
|
[6] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 21. |
700121498
|
[2] |
STRAP
|
CAS
|
| 22. |
700114001
|
[1] |
SHIELD
|
HFI
- right Superseded by part number: 700150653
|
| 23. |
700133683
|
[1] |
SHIELD
|
HFI
- front, right Superseded by part number: 700138239
|
| 24. |
121-115
|
[6] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 25. |
700133680
|
[1] |
SHIELD
|
HFI
- right
|
| 26. |
700114003
|
[1] |
CHANNEL
|
CAS
- right
|
| 27. |
700114019
|
[1] |
ROD
|
CAS
HINGE - pin, right
|
| 28. |
700709850
|
[2] |
SHIELD
|
CAS
- belting
|
| 29. |
230-4115
|
[4] |
LOCK NUT,5/16"-18, GA
|
CAS
5/16-18 HTLN GR/B Superseded by part number: 230-4145
|
| 30. |
700121668
|
[1] |
SHIELD
|
ZED
|
