凯斯零件查询(8590) - CASE IH LARGE RECTANGULAR BALER (EUROPE) (1/97-12/98) (4-14) - ELECTRICAL HARNESS SERVICE PARTS, (CON'T) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
547 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
1714005
|
[1] |
PACKAGE,SERVICE
|
IH
KIT - harness repair (Female end) Superseded by part number: 700710620, 87675194, 900401, 84471900
|
| 2. |
700708333
|
[1] |
WIRE
|
CAS
- test
|
| 3. |
700707012
|
[1] |
TERMINAL CONNECTOR
|
CAS
TOOL - connector repair Superseded by part number: 1964525C1
|
| 4. |
700707014
|
[1] |
TERMINAL CONNECTOR
|
CAS
TOOL - connector repair Superseded by part number: 1964864C1
|
| 5. |
131503C1
|
[1] |
TOOL
|
CAS
- connector repair Superseded by part number: CAS1631
|
| 6. |
700707015
|
[1] |
TANK
|
CAS
CAP - sealing
|
| 7. |
700709233
|
[1] |
CLAMP
|
CAS
- cable (Shell size 11) Superseded by part number: 247725A1
|
| 8. |
700712983
|
[1] |
CAP
|
CAS
- sealing (Shell size 23)
|
| 9. |
CAS745216
|
[1] |
CAP
|
CAS
- sealing
|
| 10. |
700711660
|
[1] |
SEAL
|
CAS
Superseded by part number: S114398
|
| 11. |
700712896
|
[1] |
SEAL
|
CAS
|
| 12. |
700706400
|
[1] |
PLUG
|
IH
SEAL Superseded by part number: 84286327
|
| 13. |
700706401
|
[1] |
TERMINAL
|
CAS
- pin, male Superseded by part number: 225120C1
|
| 14. |
700708757
|
[1] |
ELEC. TERMINAL PIN,18 - 16 SAE
|
CAS
PIN
|
| 15. |
700708758
|
[1] |
TERMINAL
|
CAS
SOCKET - type III, sel. gold/nickel
|
| 16. |
700708760
|
[1] |
ELEC. TERMINAL PIN,18 - 20 SAE
|
IH
- sleeve Superseded by part number: 225123C1
|
| 17. |
700713300
|
[1] |
ELEC CONNECTOR
|
CAS
PLUG ASSEMBLY - service, standard sex, free hanging, w/peripheral seal
|
| 18. |
60-6126T2
|
[1] |
CONNECTION
|
L
RING - coupling Superseded by part number: 225426C1
|
| 19. |
60-6127T2
|
[1] |
CONNECTION
|
L
RING - coupling
|
| 20. |
1301191C1
|
[1] |
CONNECTION
|
IH
RING - coupling Superseded by part number: 86594691
|
| 21. |
60-6129T2
|
[1] |
CONNECTION
|
L
RING - coupling
|
| 22. |
1713999
|
[1] |
PACKAGE,SERVICE
|
CAS
KIT - harness repair (Male end) Superseded by part number: 87697614, 84471900, 225362C1, 225167C1
|
