凯斯零件查询(8590) - CASE IH LARGE RECTANGULAR BALER (EUROPE) (1/97-12/98) (7-28) - TOOL BOX AND SHIELD ASSEMBLIES, FRONT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
285 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700133726
|
[1] |
SHIELD
|
HFI
WA - left
|
| 2. |
700108569
|
[1] |
LID
|
CAS
- tool box
|
| 3. |
700108566
|
[1] |
TOOL BOX
|
CAS
BOX WA - tool
|
| 4. |
409-7612
|
[2] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HFSS Superseded by part number: 72187187, 255918
|
| 5. |
231-5146
|
[11] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 6. |
700108570
|
[1] |
ROD
|
CAS
- hinge
|
| 7. |
700707858
|
[2] |
SNAP RING
|
CAS
RETAINER - stud
|
| 8. |
700133738
|
[1] |
SHIELD
|
HFI
WA - flywheel Superseded by part number: 700139376
|
| 9. |
121-226
|
[9] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 10. |
409-7624
|
[4] |
BOLT,Hex Flg, 3/8" - 16 x 1 1/2", Spcl
|
CAS
Superseded by part number: 86512175
|
| 11. |
700133729
|
[1] |
SHIELD
|
HFI
WA - right
|
| 12. |
700114023
|
[1] |
SHIELD
|
CAS
|
| 13. |
700114024
|
[1] |
ANGLE
|
CAS
|
| 15. |
232-5316
|
[4] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 16. |
700133724
|
[2] |
SUPPORT
|
HFI
- reflector
|
