凯斯零件查询(8590) - CASE IH LARGE RECTANGULAR BALER (EUROPE) (1/97-12/98) (7-32) - BRAKE CONTROL ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
971 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
515-23190
|
[3] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line 3/4", Insul, 3/8" Bolt Superseded by part number: 86624005
|
| 2. |
121-226
|
[9] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 3. |
232-5316
|
[9] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 4. |
700133076
|
[1] |
SUPPORT
|
HFI
- cable
|
| 5. |
700714993
|
[1] |
CABLE
|
CAS
WIRE ROPE - handbrake
|
| 6. |
700708090
|
[1] |
CLAMP
|
L
- line Superseded by part number: 86637978
|
| 7. |
172463
|
[1] |
SELF-TAP SCREW,Hex Hd, 5/16" x 1"
|
CAS
5/16-18 X 3/4 HWHTCTS
|
| 8. |
700715228
|
[1] |
FLEXIBLE HOSE
|
ZED
HOSE ASSEMBLY
|
| 9. |
700716972
|
[2] |
ACTUATOR
|
CAS
RAM ASSEMBLY - brake
|
| 10. |
700715230
|
[2] |
LEVER
|
ZED
- brake cam
|
| 11. |
700715959
|
[2] |
WASHER
|
ZED
- special
|
| 12. |
700715958
|
[2] |
LOCKING RING
|
ZED
RING - retaining, external
|
| 13. |
700714994
|
[4] |
CLAMP
|
CAS
- handbrake cable
|
| 14. |
700714996
|
[1] |
COUPLING
|
CAS
- trailer
|
| 15. |
700715004
|
[1] |
HOSE
|
CAS
ASSEMBLY
|
| 16. |
700716814
|
[1] |
LEVER
|
CAS
ASSEMBLY - handbrake
|
| 17. |
163-41
|
[1] |
SCREW,Sl Hex Wshr Hd, 5/16" - 18 x 1 1/4"
|
CAS
5/16-18 X 1-1/4 HWHMS
|
| 18. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 19. |
700120328
|
[1] |
PULLEY
|
HFI
|
| 20. |
700133077
|
[2] |
SUPPORT
|
HFI
- pulley
|
| 21. |
700119414
|
[1] |
SPACER
|
CAS
BUSHING - spacer
|
| 22. |
700715006
|
[1] |
3 WAY CONNECTION
|
CAS
TEE - straight, BSP
|
| 23. |
700133073
|
[1] |
SUPPORT
|
HFI
- angle
|
| 24. |
700715204
|
[2] |
FLEXIBLE SHEATH
|
CAS
COVER - handbrake cable Superseded by part number: 700714993
|
| 25. |
L18337
|
[12] |
CABLE TIE,9.95"-12.1" lg
|
CAS
STRAP - tie, 15 inch, nylon Superseded by part number: 529070
|
