沃尔沃零件查询MD40A; TMD40A; TMD40B; TMD40C; AQD40A; TAMD40A; TAMD40B; AD40B; AQAD40A; AQAD40BTransmissionsConnecting Components Reverse Gear Borg WarnerEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
494 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
|
|
|
|
| 2. |
803921
|
[1] |
Gasket
|
|
| 3. |
953081
|
[6] |
Stud
|
|
| 4. |
941908
|
[6] |
Spring washer
|
|
| 5. |
955783
|
[6] |
Hexagon nut
|
|
| 6. |
842998
|
[1] |
Bracket
|
|
| 7. |
941909
|
[2] |
Spring washer
|
|
| 8. |
955548
|
[2] |
Hexagon screw
|
|
| 9. |
842240
|
[1] |
Oil cooler, oil cooler
|
|
| 10. |
842244
|
[1] |
Tensioning band
|
|
| 11. |
941907
|
[2] |
Spring washer
|
|
| 12. |
955295
|
[2] |
Hexagon screw
|
|
| 13. |
957184
|
[2] |
Gasket
|
|
| 14. |
943755
|
[2] |
Fitting
|
|
| 15. |
956970
|
[4] |
Ferrule
|
|
| 16. |
956984
|
[2] |
Fitting nut
|
|
| 16A. |
941331
|
[2] |
Fitting nut
|
|
| 17. |
941750
|
[1] |
Nipple
|
|
| 18. |
804533
|
[1] |
Nipple
|
|
| 19. |
941757
|
[1] |
Elbow nipple
|
Alt
|
| 19. |
941750
|
[1] |
Nipple
|
Alt
|
| 20. |
829259
|
[1] |
Hose assembly
|
L=360mm
|
| 21. |
829260
|
[1] |
Hose
|
L=500mm
|
| 22. |
844359
|
[1] |
Bracket
|
|
| 23. |
819068
|
[1] |
Washer
|
|
| 24. |
21471054
|
[1] |
Bracket
|
|
| 25. |
950021
|
[2] |
Cross recessed screw
|
|
| 26. |
813674
|
[1] |
Cube
|
|
| 27. |
940191
|
[1] |
Washer
|
|
| 28. |
907834
|
[1] |
Split pin
|
(17276)
|
| 29. |
829053
|
[1] |
Connecting hook
|
|
| 30. |
843438
|
[1] |
Hose
|
|
| 31. |
994560
|
[6] |
Hose clamp
|
|
| 32. |
941799
|
[1] |
Hose
|
L=65mm
|
| 33. |
845848
|
[1] |
Coolant pipe
|
|
| 34. |
858039
|
[1] |
Coolant pipe
|
See group 2B
|
| 35. |
82745
|
[1] |
Shut-off cock
|
|
| 36. |
|
|
|
See group 9
|
