| 1. |
6530232
|
[1] |
ARM
|
CAS
TRIP ARM WA Superseded by part number: 700161048
|
| 2. |
38-11624
|
[1] |
LOCK PIN,1/4" x 1 1/2", Slotted
|
CAS
PIN, 1/4" x 1 1/2", Slotted Superseded by part number: 87406
|
| 3. |
700123850
|
[2] |
SHIELD
|
CAS
- wheel
|
| 4. |
111-360
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 5. |
329-286
|
[9] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 6. |
6530646
|
[1] |
BUSHING
|
CAS
- pivot
|
| 7. |
6530489
|
[1] |
HUB
|
CAS
SPACER - hub
|
| 8. |
700134937
|
[1] |
SUPPORT
|
CAS
- spring
|
| 9. |
232-53110
|
[1] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 10. |
758441
|
[1] |
SPRING
|
IH
|
| 11. |
413-620
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 12. |
495-21044
|
[1] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 13. |
700113105
|
[1] |
ROD
|
HFI
- starwheel
|
| 14. |
6530588
|
[1] |
ARM
|
CAS
WA
|
| 15. |
495-21056
|
[4] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 16. |
432-1016
|
[2] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 17. |
6530638
|
[1] |
BUSHING
|
CAS
- pivot
|
| 18. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 19. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
1/8" x 1" Superseded by part number: 80755
|
| 20. |
066183
|
[1] |
CLEVIS
|
IH
Superseded by part number: 70937465
|
| 21. |
427-8150
|
[1] |
CLEVIS PIN,1/2" x 1 1/2"
|
CAS
1/2X1.500 1.281 HD/HOLE CLEVIS ZND
|
| 22. |
433-840
|
[1] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 2 1/2", Gr 5
|
CAS
1/2-13 X 2-1/2 RHSNB Superseded by part number: 280435
|
| 23. |
700711557
|
[4] |
WASHER
|
CAS
1/2 HARDENED WIDE PLAIN WASHER
|
| 24. |
700714586
|
[1] |
FLANGE NUT
|
CAS
1/2-13 HFN GR8 Superseded by part number: 329-288
|
| 25. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 26. |
496-11041
|
[6] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 27. |
434-616
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 28. |
700134449
|
[1] |
ANGLE
|
CAS
- support
|
| 29. |
700134527
|
[1] |
SHAFT
|
CAS
- adjust
|
| 30. |
425-148
|
[1] |
JAM NUT,Jam, 1/2"-13, G5
|
CAS
Superseded by part number: 86632558
|
| 31. |
58024
|
[1] |
SPRING
|
IH
- compression
|
| 32. |
6530307
|
[1] |
SPROCKET ASSY.
|
CAS
STARWHEEL
|
| 33. |
700137490
|
[1] |
ARM
|
CAS
ASSEMBLY (Includes Ref: 34)
|
| 34. |
B18254
|
[1] |
NEEDLE BEARING,Needle, 25.4mm ID x 31.75mm OD x 25.4mm W
|
CAS
BEARING - needle
|
| 35. |
232-53112
|
[1] |
FLANGE NUT,Flg, 3/4"-10
|
CAS
3/4-10 HFTLN GR/G Superseded by part number: 86512372
|
| 36. |
700124056
|
[1] |
ROLLER
|
CAS
- clutch
|
| 37. |
100-1175
|
[2] |
SNAP RING,#75, Ext
|
CAS
Ring, Snap, #75, Ext Superseded by part number: 72186587, 129164
|
| 38. |
6525042
|
[1] |
ROLLER,41.28mm OD x 12.5mm L
|
CAS
- clutch
|
| 39. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 40. |
700137491
|
[1] |
BOLT
|
CAS
- special, needle brg Superseded by part number: 700137492
|
| 41. |
700134938
|
[1] |
CRANKED HANDLE
|
CAS
CRANK WA
|
| 42. |
700133656
|
[1] |
SHIELD
|
HFI
WA - starwheel
|
| 43. |
111-237
|
[2] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5 Superseded by part number: 33-516
|
| 44. |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 45. |
256873
|
[4] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 46. |
700133658
|
[1] |
COVER
|
HFI
- starwheel
|
| 47. |
121-115
|
[2] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 48. |
700134931
|
[1] |
BRACKET
|
CAS
WA - starwheel
|
| 49. |
6234710
|
[1] |
SPACER
|
CAS
|
| 50. |
827360
|
[2] |
HANDLE
|
CAS
GRIP
|
| 51. |
700134935
|
[1] |
LEVER
|
CAS
ASSEMBLY
|
