沃尔沃零件查询MD5A; MD5B; MD5CCooling SystemWater PumpEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
600 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
833883
|
[1] |
Water pump
|
Replaced by 858065
|
| 1. |
858065
|
[1] |
Sea water pump
|
|
| 2. |
21951368
|
[1] |
Wear kit
|
|
| 3. |
833416
|
[1] |
Pump cam
|
|
| 4. |
833992
|
[1] |
Cap
|
|
| 5. |
833994
|
[1] |
Gasket
|
|
| 6. |
840771
|
[1] |
Wear washer
|
|
| 7. |
826239
|
[1] |
Pin
|
|
| 8. |
804693
|
[1] |
Screw
|
|
| 9. |
833996
|
[1] |
Sealing ring
|
|
| 10. |
859101
|
[1] |
Spacer washer
|
|
| 11. |
21951422
|
[1] |
Shaft kit
|
|
| 12. |
827014
|
[1] |
Pump shaft
|
|
| 13. |
833996
|
[1] |
Sealing ring
|
|
| 14. |
181717
|
[2] |
Ball bearing
|
|
| 15. |
914515
|
[1] |
Snap ring
|
|
| 16. |
3586496
|
[1] |
Impeller kit
|
Replaced by next part number
|
| 16. |
21951342
|
[1] |
Impeller kit
|
|
| 17. |
|
|
|
|
| 18. |
833994
|
[1] |
Gasket
|
|
| 19. |
21951302
|
[1] |
Screw kit
|
|
| 20. |
21643469
|
[4] |
Hexagon screw
|
|
