神钢零件查询(BREAKER) - ATTACHMENT (N&B) - SK115SR & SK135SR - ASN YV04, YY04, YH04-03001 (9/04-) (02-022) - ARM 2.2M (YV12B00090F5) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
777 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YV12B00090F5 | [1] | ARM ASSY, 2. 2M (EXTRA) | |
| . . | YV12B00090F7 | [1] | ARM ASSY, 2. 2M (EXTRA + NIBBLER & BREAKER) | |
| 2. | YV12B01068P1 | [2] | BUSHING | KOB Superseded by part number: YW12B01036P1 |
| 3. | YW12B01042P1 | [2] | BUSHING | KOB |
| 4. | YX12B01021P1 | [2] | BUSHING | KOB |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONPLATE (F5 ONLY) |
| 8-2. | 2416T9878D2 | [2] | BLOCK | KOB |
| 8-3. | 2416T9878D4 | [1] | BLOCK | KOBBLOCK, TAPPED |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONARM (F7 ONLY) |
| 10-6. | 2416T5009D2 | [2] | BLOCK | KOB |
| 10-7. | YN43H01051P1 | [1] | BLOCK | KOB |
| 10-8. | 2416T9878D2 | [1] | BLOCK | KOB |
| 10-9. | YV12B01070P1 | [1] | BLOCK | KOBBLOCK, TAPPED |
