| . . | 24100J15308F1 | [1] | REMOTE-CONTROL ASSY | |
| 1. | 24100J15269F1 | [1] | REMOTE CONTROL ASSY, Remarks: P. 161-50 | |
| 3. | 2436U1142F1 | [1] | PILOT VALVE | KOBVALVE, PILOT, Remarks: SEE (C. P. M) |
| 4. | 2436U1314F1 | [1] | VALVE | KOBSOLENOID, Remarks: SEE (C. P. M) |
| 5. | 2406P5346 | [1] | PEDAL | KOB |
| 6. | 24100P2919F1 | [1] | LOCK | KOBASSY, APPLICABLE: YQU?-? YNU?-? |
| . . | 24100P2919F4 | [1] | LOCK | KOBASSY, APPLICABLE: YQU?- YNU?- |
| 6-1. | 2416P15115D1 | [1] | SUPPORT, APPLICABLE: YQU?-? YNU?-? | |
| 6-2. | 2406P4095 | [1] | LOCK | KOBLEVER |
| 6-3. | 2417T533 | [1] | SPRING | KOB |
| 6-4. | 2419T3784D1 | [1] | PIN | KOB |
| 6-5. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 6-6. | ZP16D04022 | [1] | PIN, SPLIT | |
| 6-9. | 2416P18650D1 | [1] | SUPPORT | KOBAPPLICABLE: YQU?- YNU? |
| 7. | 2414P8766 | [1] | TRIM | KOB |
| 8. | 2412T953 | [1] | DECAL | KOBSTICKER |
| 9. | 2479Z849 | [1] | SWITCH | KOBSWICH, TOGGLE Superseded by part number: 2479Z514 |
| 10. | 2479Z976D4 | [1] | HARNESS | KOB |
| 11. | 2479Z977 | [1] | HARNESS | KOB |
| 12. | 2479Z1441D2 | [1] | HARNESS | KOB |
| 13. | ZH52X04000 | [4] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 14. | 2444T2592 | [1] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 15. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 16. | 2444Z2530 | [1] | TEE | TEE |
| 17. | 2444Z2359 | [1] | TEE | KOB3/8" PT (Incls. O-Ring ZD12P01400) |
| 18. | 2444Z2461 | [1] | TEE | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 19. | 2444Z2544 | [2] | TEE | KOB1/4"PTx60mm Long (No O-Ring supplied) |
| 20. | ZH22X04000 | [5] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 21. | 2444Z2335 | [1] | CONNECTION | KOBCONNECTOR |
| 22. | 2444Z3179D2 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 23. | ZH32X04000 | [10] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 24. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 25. | 2444Z2894 | [2] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 26. | 2444Z4081 | [1] | ELBOW | KOB Superseded by part number: HH35X04004G3 |
| 27. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 28. | 2420R349D050 | [1] | HOSE,500.00 mm | KOB500mm Long (19-11/16 in) |
| 30. | 2420R349D070 | [1] | HOSE,700.00 mm | KOB700mm Long (27-9/16 in) |
| 31. | 2420R349D075 | [1] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 32. | 2420R349D080 | [1] | HOSE,6.35mm ID x 800mm L | KOB800mm Long (31-1/2 in) |
| 33. | 2420R349D100 | [1] | HOSE | KOB1000mm Long (39-3/8 in) Superseded by part number: HX21E04100DX |
| 35. | 2420R349D115 | [2] | HOSE,1150.00 mm | KOB Superseded by part number: HX21E04115DX |
| 37. | 2420R349D150 | [1] | HOSE,6.35mm ID x 1500mm L | KOBPF 1/4, APPLICABLE: YQU00701-? YNU?-? |
| . . | 2420R1182D150 | [1] | FLEXIBLE HOSE | KOBHOSE, APPLICABLE: YQU?- YNU?- Superseded by part number: HX21E04150DX |
| 38. | 2420R349D240 | [2] | HOSE,2400.00 mm | KOBAPPLICABLE: YQU?-? YNU?-? 2400.00 mm Superseded by part number: HX21E04240DX |
| . . | 2420R1182D240 | [2] | HOSE, APPLICABLE: YQU?- YNU?- | HOSE, APPLICABLE: YQU?- YNU?- |
| 39. | 2420R349D250 | [1] | HOSE,2500.00 mm | KOB2500mm, APPLICABLE: YQU?-? YNU?-? |
| . . | 2420R1182D250 | [1] | HOSE, APPLICABLE: YQU?- YNU? | HOSE, APPLICABLE: YQU?- YNU? |
| 40. | 2420R349D260 | [1] | HOSE | KOB2600mm Long (102-23/64 in), APPLICABLE: YQU?-? YNU00001-? Superseded by part number: HX21E04260DX |
| . . | 2420R1182D260 | [1] | HOSE, APPLICABLE: YQU?- YNU?- | HOSE, APPLICABLE: YQU?- YNU?- |
| 41. | 2444R963D6 | [1] | HOSE | KOBAPPLICABLE: YQU?-? YNU?- |
| . . | 2420R1184D060 | [1] | HOSE, APPLICABLE: YQU?- YNU?- | HOSE, APPLICABLE: YQU?- YNU?- |
| 42. | 2444R963D20 | [1] | FLEXIBLE HOSE | KOB350 mm long (13-49/64 in), Applicable: YQU?-? YNU?- Superseded by part number: 77258641, HX31E04035DX |
| . . | 2420R1184D035 | [1] | HOSE, APPLICABLE: YQU?- YNU?- | HOSE, APPLICABLE: YQU?- YNU?- |
| 43. | 2444R963D32 | [1] | HOSE | KOBAPPLICABLE: YQU?-? YNU?-? |
| . . | 2420R1184D030 | [1] | HOSE, APPLICABLE: YQU?- YNU?- | HOSE, APPLICABLE: YQU?- YNU?- |
| 44. | 2444R1119D044 | [1] | HOSE | KOB Superseded by part number: 2444R1119D046 |
| 45. | ZS13C06020 | [2] | M06x1.0x20mm | M06x1.0x20mm |
| 46. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 47. | ZS23C10016 | [1] | SCREW,Hex Socket Head, M10 x 16mm | KOBM10x1.50x16mm Superseded by part number: ZS28C10016 |
| 48. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 49. | ZW22X06000 | [2] | ID 06 x OD 12.2 x Th 1.5mm | ID 06 x OD 12.2 x Th 1.5mm |
| 50. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 51. | ZW22K10000 | [1] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 52. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 53. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm, APPLICABLE: YQU?- YNU?- |
