凯斯零件查询(LB324P) - BALER (9/12-) (33.110.010) - PARKING BRAKE, TANDEM AXLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
345 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84078394
|
[2] |
SUPPORT
|
ZED
|
| 2. |
84078393
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84411803
|
[2] |
CABLE,3570mm L
|
ZED
|
| 3. |
48026072
|
[2] |
|
CABLE
|
| 4. |
748797
|
[2] |
WASHER,10.5mm ID x 25mm OD x 7mm L
|
ZED
|
| 5. |
84274758
|
[1] |
HAND BRAKE
|
ZED
|
| 5. |
47980417
|
[1] |
|
HAND BRAKE
|
| 6. |
43139
|
[4] |
BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
Superseded by part number: 11106231
|
| 7. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 8. |
100016
|
[4] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
9706687
|
[1] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 10. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 11. |
100038
|
[6] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 12. |
9706702
|
[1] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
NH
|
| 13. |
84607247
|
[4] |
WIRE CLAMP
|
ZED
|
| 14. |
322901
|
[2] |
PIN,10mm OD x 30mm L
|
ZED
|
| 15. |
130003
|
[2] |
COTTER PIN,3mm OD x 30mm OAL
|
ZED
|
| 16. |
378244
|
[2] |
WASHER,10.5mm ID x 24mm OD x 2mm Thk
|
NH
|
| 17. |
84429166
|
[2] |
BRACKET
|
ZED
|
| 18. |
84078395
|
[2] |
ROLLER,60mm OD x 11.5mm L
|
ZED
|
| 19. |
9838358
|
[2] |
BUSHING,13mm ID x 22mm OD x 13mm L
|
ZED
|
| 20. |
86629541
|
[4] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 21. |
86566989
|
[2] |
CABLE TIE,208mm L
|
ZED
|
| 21. |
86566990
|
[4] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 22. |
47979954
|
[1] |
PADLOCK
|
ZED
|
