| . . | 24100J15276F3 | [1] | 5.6M BOOM ASSY | |
| 2. | 2438U1102F1 | [1] | CYLINDER | KOBCYLINDER, Remarks: SEE (C. P. M) |
| 3. | 2438U1103F1 | [1] | CYLINDER | KOBCYLINDER, Remarks: SEE (C. P. M) |
| 4. | 2438U1104F1 | [1] | CYLINDER | KOBCYLINDER, Remarks: SEE (C. P. M) Superseded by part number: 2438U1108F1, 2418P22219D1 |
| 5. | 2418P26577 | [1] | TUBE TUBE | TUBE TUBE |
| 6. | 2418P26578 | [1] | TUBE TUBE | TUBE TUBE |
| 7. | 2418P27922 | [1] | RIGID TUBE | KOBTUBE |
| 8. | 2418P26580 | [1] | TUBE | KOBTUBE |
| 9. | 2418P26581 | [2] | RIGID TUBE | KOBTUBE |
| 10. | 2418P22219D2 | [1] | RIGID TUBE | KOBTUBE |
| 11. | 2444R1176D1 | [2] | FLEXIBLE HOSE | KOB940mm Long (37 in), APPLICABLE: YQU01027-01244 YNU00109-00137 Superseded by part number: 2444R1090D1 |
| . . | 2444R1176D1 | [3] | FLEXIBLE HOSE | KOB940mm Long (37 in), APPLICABLE: YQU01245- YNU00138- Superseded by part number: 2444R1090D1 |
| 12. | 2418P21596D1 | [1] | TUBE | KOBTUBE |
| 13. | 2418P21596D2 | [1] | TUBE | KOBTUBE |
| 14. | 2418P27601 | [1] | RIGID TUBE | KOBTUBE |
| 15. | 2418P18412 | [1] | RIGID TUBE | KOBTUBE |
| 16. | 2444R1177D2 | [2] | FLEXIBLE HOSE | KOB940mm Long (37 in), APPLICABLE: YQU01027-01244 YNU00109-00137 |
| . . | 2444R1177D2 | [3] | FLEXIBLE HOSE | KOB940mm Long (37 in), APPLICABLE: YQU01245- YNU00138- |
| 17. | 2444R1090D1 | [2] | HOSE | KOBHOSE, APPLICABLE: YQU01027-01244 YNU00109-00137 |
| 18. | ZX26T12080 | [2] | FLEXIBLE HOSE | KOBHOSE, APPLICABLE: YQU01027-01244 YNU00109-00137 Superseded by part number: 2444R1177D1 |
| . . | 2444R1177D1 | [2] | FLEXIBLE HOSE | KOB800mm Long (31-1/2 in), APPLICABLE: YQU01245- YNU00138- |
| 19. | 2444R1169D2 | [2] | HOSE | KOB800mm Long (31-1/2 in) |
| 20. | ZX26T16080 | [1] | FLEXIBLE HOSE | KOBHOSE, APPLICABLE: YQU01027-01244 YNU00109-00137 Superseded by part number: 2444R1175D1 |
| . . | 2444R1175D1 | [1] | HOSE | KOB800mm Long (31-1/2 in), APPLICABLE: YQU01245- YNU00138- |
| 21. | 2420R1187D305 | [1] | HOSE,6.40mm ID x 3050mm L | KOBHOSE HOSE Superseded by part number: HX21E04305DY |
| 22. | 2420R1187D235 | [1] | HOSE,6.40mm ID x 2350mm L | KOBHOSE HOSE Superseded by part number: HX21E04235DY |
| 23. | 2420R1187D088 | [2] | HOSE,6.40mm ID x 880mm L | KOBHOSE HOSE Superseded by part number: HX21E04235DY |
| 24. | ZF23B28000 | [2] | HYD CONNECTOR | KOB Superseded by part number: 47641651 |
| 25. | ZH22Z04000 | [3] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 26. | 2444R2522D1 | [1] | FLEXIBLE HOSE | KOB900mm Long (35-7/16 in) |
| 27. | ZG91S02000 | [9] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 28. | ZH32Z04000 | [2] | ELBOW | KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100) |
| 29. | 2432T2434 | [4] | CLAMP | KOBDouble Line -- 129x38x15mm (Ø29xØ36mm) |
| 30. | ZC26X28014 | [8] | CLAMP | KOBSingle Line -- 75x37x38mm (Ø28mm) |
| 31. | 2432T2522D2 | [2] | CLAMP | KOBCLAMP |
| 32. | 2432T2363 | [1] | CLAMP | KOB Superseded by part number: YN42H01078P1 |
| 33. | ZC36X28014 | [1] | CLAMP | KOBDouble Line -- 100x38x16mm (Ø30mm) |
| 34. | ZC36X35016 | [1] | CLAMP | KOBCLAMP |
| 35. | ZS13C10020 | [1] | SCREW | KOBM10x1.50x20mm Superseded by part number: ZS18C10020 |
| 36. | ZS13C10060 | [8] | SCREW | KOBM10x1.50x60mm Superseded by part number: ZS18C10060 |
| 37. | ZS13C10055 | [10] | SCREW | KOBM10x1.50x55mm Superseded by part number: ZS18C10055 |
| 38. | ZS13C10040 | [2] | SCREW | KOBM10x1.50x40mm Superseded by part number: ZS18C10040 |
| 39. | ZS13C12055 | [13] | SCREW | KOBM12x1.75x55mm Superseded by part number: ZS18C12055 |
| 40. | ZS13C12065 | [1] | SCREW | KOBM12x1.75x65mm Superseded by part number: ZS18C12065 |
| 41. | ZS13C12090 | [4] | SCREW | KOBM12x1.75x90mm Superseded by part number: ZS18C12090 |
| 42. | ZS13C14030 | [4] | SCREW | KOBM14x2.0x30mm Superseded by part number: ZS18C14030 |
| 43. | ZS13C14065 | [1] | SCREW | KOBM14x2.0x65mm Superseded by part number: ZS18C14065 |
| 44. | ZS13C16030 | [2] | SCREW | KOBM16x2.0x30mm |
| 45. | 2420T4330D2 | [3] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm Superseded by part number: HS18C16150G1 |
| 46. | 2420R1187D245 | [1] | HOSE,6.40mm ID x 2450mm L | KOBHOSE HOSE Superseded by part number: HX21E04245DY |
| 47. | ZN13C16013 | [6] | NUT | KOBM16x2.0mm |
| 48. | ZW22X10000 | [25] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 49. | ZW22X12000 | [18] | LOCK WASHER | KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000 |
| 50. | ZW22X14000 | [11] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 51. | ZW22X16000 | [2] | WASHER, LOCK | KOBID 16 x OD 28.0 x Th 4.0mm |
| 52. | ZD12P02600 | [4] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 53. | ZD12P03400 | [2] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 54. | 2445R220D6 | [2] | SEAL,90mm ID x 105mm OD x 6mm Thk | KOBDust -- ID 90 X OD 105 x Th 6mm |
| 55. | 2419T4651 | [1] | PIN | KOBPIN Superseded by part number: 2419T7607, 2419T5490 |
| 56. | 2419P1707D1 | [1] | PIN | KOBPIN |
| 57. | 2419P3687 | [2] | PIN | KOBPIN |
| 58. | 2419P3414 | [1] | LARGE PIN | KOBPIN, LARGE PIN |
| 59. | 2419T6440 | [1] | PIN | KOBPIN Superseded by part number: 2419T7613 |
| 60. | 2416T13056 | [1] | BRACKET | KOBBRACKET |
| 61. | 2418T12469 | [2] | PLATE | KOB150 x 50 x Th 12mm, 2-Ø16 Holes |
| 62. | 2418T17550 | [2] | PLATE | KOBID 18 x OD 60 x Th 06mm |
| 63. | ZS23C12040 | [4] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 64. | 2411T671D5 | [2] | BOSS | KOBBOSS |
| 65. | B16T0442D3 | [2] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOBID 82 x OD 150 x Th 1.2mm |
| 66. | B16T0442D4 | [2] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 67. | B16T0442D6 | [2] | SHIM,150mm OD x 82mm ID x 2.3mm Thk | KOBID 82 x OD 150 x Th 2.3mm |
| 68. | ZE13X16000 | [2] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 69. | B16T0442D62 | [3] | SHIM,87mm ID x 140mm OD x 1.6mm Thk | KOBID 87 x OD 140 x Th 1.6mm |
| 70. | ZW22K12000 | [4] | LOCK WASHER | KOBID 12.2 x OD 17.8 x Th 2.5mm |
| 71. | B16T0442D40 | [1] | SHIM,92mm ID x 160mm OD x 0.9mm Thk | KOBID 92 x OD 160 x Th 0.9mm |
| 72. | B16T0442D13 | [1] | SHIM,160mm OD x 92mm ID x 1.2mm Thk | KOBID 92 x OD 160 x Th 1.2mm |
| 73. | B16T0442D14 | [1] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOBID 92 x OD 160 x Th 1.6mm |
| 74. | B16T0442D15 | [1] | SHIM,160mm OD x 92mm ID x 2.3mm Thk | KOBID 92 x OD 160 x Th 2.3mm |
| 81. | 2418P18410 | [1] | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 |
| . . | 2418P28993 | [1] | TUBE | KOBTUBE, APPLICABLE: YQU01245- YNU00138- |
| 82. | 2418T18224 | [1] | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 |
| . . | 2418P28994 | [1] | TUBE | KOBTUBE |
| 83. | 2418T18223 | [1] | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 |
| . . | 2418P28995 | [1] | TUBE | KOBTUBE, APPLICABLE: YQU01245- YNU00138- |
| 84. | 2418T18225 | [1] | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 | TUBE TUBE, APPLICABLE: YQU01027-01244 YNU00109-00137 |
| . . | 2418P28996 | [1] | TUBE | KOBTUBE, APPLICABLE: YQU01245- YNU00138- |
| 85. | B16T0442D53 | [1] | SHIM,92mm ID x 160mm OD x 0.5mm Thk | KOBID 92 x OD 160 x Th 0.5mm |
| 86. | 2444R1133D5 | [4] | HOSE | KOB760mm Long (29-59/64 in) |
| 87. | 2444R1102D2 | [1] | HOSE | KOBHOSE |
| 88. | 2436R767F2 | [2] | VALVE | KOBASSY, SEE (C. P. M) |
| 89. | 2432R240F1 | [2] | U-BRACKET | KOBBAND ASSY |
| 89-1. | 2438U914D1S24 | [1] | U-BRACKET | KOBBAND |
| 89-2. | 2436R764S2 | [1] | BAND PLATE, SUB | BAND PLATE, SUB |
| 89-3. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 89-4. | ZS11C10035 | [2] | SCREW,Hex, M10 x 35mm, Cl 4.8 | KOBCAPSCREW Superseded by part number: ZS18C10035 |
| 89-5. | ZS23C10025 | [2] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 89-6. | ZN16C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 90. | 2432T2340 | [2] | CLAMP | KOB |
| 91. | ZA23F15006 | [2] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
| 92. | ZA23F15008 | [2] | HYD CONNECTOR | KOB |
| 93. | B16T0442D52 | [3] | SHIM,82mm ID x 100mm OD x 0.5mm Thk | KOBID 82 x OD 150 x Th 0.5mm |
| 94. | ZA33F10004 | [2] | ELBOW | KOB |
| 95. | ZD12P01400 | [2] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 96. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 97. | ZD12P01100 | [2] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 98. | ZS23C10060 | [8] | SCREW,Hex Socket Head, M10 x 60mm | KOBM10x1.50x60mm |
| 99. | ZW22K10000 | [8] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 102. | B16T0442D39 | [2] | SHIM,82mm ID x 150mm OD x 0.9mm Thk | KOBID 82 x OD 150 x Th 0.9mm |
| 103. | B16T0442D76 | [3] | SHIM,140mm OD x 87mm ID x 1.2mm Thk | KOBID 87 x OD 140 x Th 1.2mm |
| 104. | B16T0442D77 | [3] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOBID 87 x OD 140 x Th 0.9mm |
| 105. | B16T0442D78 | [3] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOBID 87 x OD 140 x Th 0.5mm |
| 106. | ZS13C10025 | [4] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 107. | ZS13C10035 | [4] | SCREW | KOBM10x1.50x35mm Superseded by part number: ZS18C10035 |
| 108. | ZD12G03000 | [2] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 109. | ZN13C10008 | [4] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 200. | 2411J4693D2F1 | [1] | BOOM | |
| 200-31. | 2416T21120D2 | [8] | BLOCK | KOBBLOCK, TAPPED |
| 200-39. | 2405T1837 | [2] | BUSHING | KOBBUSHING |
| 200-43. | 2416T21120D3 | [3] | LINK BLOCK | KOBBLOCK, TAPPED |
| 200-44. | 2416T24891D2 | [2] | LINK BLOCK | KOBBLOCK, TAPPED |
| 200-45. | 2416T13325D1 | [1] | LINK BLOCK | KOBBLOCK, TAPPED |
| 200-46. | 2416T24890 | [1] | SUPPORT | |
| 201. | 2418T25245 | [2] | TUBE | KOBTUBE |
| 202. | 2418P28983 | [1] | TUBE | KOBTUBE |
| 203. | 2418T16550D2 | [1] | TUBE | |
| 205. | 2418P28982 | [1] | TUBE | KOBTUBE |
| 206. | 2418T16551 | [1] | TUBE,BRAZED TUBE | TUBE,BRAZED TUBE |
| 207. | 2418P29035D1 | [1] | TUBE | KOBTUBE |
| 208. | 2418P29035D2 | [1] | TUBE | KOBTUBE |
| 210. | ZX26T12094 | [1] | FLEXIBLE HOSE | KOBHOSE, APPLICABLE: YQU01027-01244 YNU00109-00137 Superseded by part number: 2444R1177D2 |
| 211. | 2444R950D1 | [2] | HOSE | KOB |
| 212. | ZF23B35000 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 213. | ZA23B28035 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 220. | ZC26X35016 | [6] | CLAMP | KOBSingle Line -- 85x44x38mm (Ø35mm) |
| 222. | ZC26X18011 | [2] | CLAMP | KOBCLAMP Superseded by part number: ZC26M18011 |
| 223. | ZS13C14060 | [6] | SCREW | KOBM14x2.0x60mm Superseded by part number: ZS18C14060 |
| 225. | ZS13C10040 | [2] | SCREW | KOBM10x1.50x40mm Superseded by part number: ZS18C10040 |
| 229. | 2420Z985 | [2] | PLUG | KOBPLUG |
| 230. | 2414Z199D100 | [8] | PROTECTIVE SLEEVE | KOBHose -- 1000mm Long (39-3/8 in) |
| 231. | 24100P1005F1 | [2] | VALVE | KOBVALVE, SELECTOR Superseded by part number: 24100P1005F3 |
| 231-1. | 2436P229 | [1] | VALVE BODY | KOBBODY, VALVE |
| 231-2. | 2436T303 | [1] | VALVE | KOBVALVE |
| 231-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 231-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 231-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 231-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 231-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 231-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 231-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 231-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 232. | ZF23F28012 | [2] | HYD CONNECTOR | KOBCONNECTOR |
| 233. | 2444Z2093 | [2] | HYD CONNECTOR | KOBCONNECTOR |
| 234. | 2444T2179 | [2] | HYD CONNECTOR | KOBCONNECTOR |
| 235. | ZD12P02400 | [6] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 236. | 2432P2807 | [1] | TYPE PLATE | KOBNAME PLATE Superseded by part number: 2432P2276 |
| 237. | 2432P2806 | [1] | TYPE PLATE | KOBNAME PLATE Superseded by part number: 2432P2275 |
