神钢零件查询(BREAKER) - NIBBLER AND BREAKER ATTACHMENT - SK200LC EXCAVATORS (9/04-) (623-60) - Boom Ass'y, 5.6M (Extra Boom Arm Safety) Kobelco_神钢Kobelco_工程机械

Pos.	Part No	Qty	Parts name	Comments
. .	24100J15254F5	[1]	BOOM ASSY, 5.6M
1.	2411J5037D1F1	[1]	BOOM
1-39.	2405T1837	[2]	BUSHING	KOBBUSHING
2.	2438U1102F1	[1]	CYLINDER	KOBCYLINDER, Remarks: SEE (C. P. M)
3.	2438U1103F1	[1]	CYLINDER	KOBCYLINDER, Remarks: SEE (C. P. M)
4.	2438U1104F1	[1]	CYLINDER	KOBCYLINDER, Remarks: SEE (C. P. M) Superseded by part number: 2438U1108F1, 2418P22219D1
5.	2418P26577	[1]	TUBE TUBE	TUBE TUBE
6.	2418P26578	[1]	TUBE TUBE	TUBE TUBE
7.	2418P27922	[1]	RIGID TUBE	KOBTUBE
8.	2418P26580	[1]	TUBE	KOBTUBE
9.	2418P26581	[2]	RIGID TUBE	KOBTUBE
10.	2418P27614D2	[1]	RIGID TUBE	KOBTUBE
11.	2444R1176D1	[2]	FLEXIBLE HOSE	KOB940mm Long (37 in) Superseded by part number: 2444R1090D1
12.	2418P21596D1	[1]	TUBE	KOBTUBE
13.	2418P21596D2	[1]	TUBE	KOBTUBE
14.	2418P27601	[1]	RIGID TUBE	KOBTUBE
15.	2418P18412	[1]	RIGID TUBE	KOBTUBE
16.	2444R1177D2	[2]	FLEXIBLE HOSE	KOB940mm Long (37 in)
18.	ZX26T12080	[2]	FLEXIBLE HOSE	KOBHOSE, APPLICABLE: YQU01027-01244 YNU00109-00137 Superseded by part number: 2444R1177D1
. .	2444R1177D1	[2]	FLEXIBLE HOSE	KOB800mm Long (31-1/2 in), APPLICABLE: YQU01245- YNU00138-
19.	2444R1169D2	[2]	HOSE	KOB800mm Long (31-1/2 in)
20.	ZX26T16080	[1]	FLEXIBLE HOSE	KOBHOSE, APPLICABLE: YQU01027-01244 YNU00109-00137 Superseded by part number: 2444R1175D1
. .	2444R1175D1	[1]	HOSE	KOB800mm Long (31-1/2 in), APPLICABLE: YQU01245- YNU00138-
21.	2420R1187D305	[1]	HOSE,6.40mm ID x 3050mm L	KOBHOSE HOSE Superseded by part number: HX21E04305DY
22.	2420R1187D235	[1]	HOSE,6.40mm ID x 2350mm L	KOBHOSE HOSE Superseded by part number: HX21E04235DY
23.	2420R1187D088	[2]	HOSE,6.40mm ID x 880mm L	KOBHOSE HOSE Superseded by part number: HX21E04235DY
24.	ZF23B28000	[2]	HYD CONNECTOR	KOB Superseded by part number: 47641651
25.	ZH22Z04000	[3]	HYD CONNECTOR	KOB1/4"PTx1/4"PFx37mm Long
26.	2444R2522D1	[1]	FLEXIBLE HOSE	KOB900mm Long (35-7/16 in)
27.	ZG91S02000	[9]	LUBE NIPPLE,1/8" NPT x 1/8" NPT	KOB1/8" PT -- Straight
28.	ZH32Z04000	[2]	ELBOW	KOB90° -- (1/4" PT - 1/4" PT), (Incls. O-Ring ZD12P01100)
29.	2432T2434	[4]	CLAMP	KOBDouble Line -- 129x38x15mm (Ø29xØ36mm)
30.	ZC26X28014	[4]	CLAMP	KOBSingle Line -- 75x37x38mm (Ø28mm)
31.	2432T2522D2	[2]	CLAMP	KOBCLAMP
32.	2432T2363	[1]	CLAMP	KOB Superseded by part number: YN42H01078P1
33.	ZC36X28014	[1]	CLAMP	KOBDouble Line -- 100x38x16mm (Ø30mm)
34.	ZC36X35016	[1]	CLAMP	KOBCLAMP
35.	ZS13C10020	[1]	SCREW	KOBM10x1.50x20mm Superseded by part number: ZS18C10020
36.	ZS13C10060	[8]	SCREW	KOBM10x1.50x60mm Superseded by part number: ZS18C10060
37.	ZS13C10055	[10]	SCREW	KOBM10x1.50x55mm Superseded by part number: ZS18C10055
38.	ZS13C10040	[2]	SCREW	KOBM10x1.50x40mm Superseded by part number: ZS18C10040
39.	ZS13C12055	[9]	SCREW	KOBM12x1.75x55mm Superseded by part number: ZS18C12055
40.	ZS13C12065	[1]	SCREW	KOBM12x1.75x65mm Superseded by part number: ZS18C12065
41.	ZS13C10090	[4]	SCREW	KOBM10x1.50x90mm Superseded by part number: ZS18C10090
42.	ZS13C14030	[4]	SCREW	KOBM14x2.0x30mm Superseded by part number: ZS18C14030
43.	ZS13C14065	[1]	SCREW	KOBM14x2.0x65mm Superseded by part number: ZS18C14065
44.	ZS13C16030	[2]	SCREW	KOBM16x2.0x30mm
45.	2420T4330D2	[3]	SCREW,M16 x 2 x 150mm	KOBM16x2.0x150mm Superseded by part number: HS18C16150G1
46.	2420R1187D245	[1]	HOSE,6.40mm ID x 2450mm L	KOBHOSE HOSE Superseded by part number: HX21E04245DY
47.	ZN13C16013	[6]	NUT	KOBM16x2.0mm
48.	ZW22X10000	[36]	LOCK WASHER	KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000
49.	ZW22X12000	[34]	LOCK WASHER	KOBID 12 x OD 21.5 x Th 3.0mm Superseded by part number: ZW26X12000
50.	ZW22X14000	[5]	LOCK WASHER	KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000
51.	ZW22X16000	[2]	WASHER, LOCK	KOBID 16 x OD 28.0 x Th 4.0mm
52.	ZD12P02600	[5]	O-RING	KOBID 25.70 ± 0.26 x OD 32mm
53.	ZD12P03400	[1]	O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro	KOBID 33.70 ± 0.33 x OD 40mm
54.	2445R220D6	[2]	SEAL,90mm ID x 105mm OD x 6mm Thk	KOBDust -- ID 90 X OD 105 x Th 6mm
55.	2419T4651	[1]	PIN	KOBPIN Superseded by part number: 2419T7607, 2419T5490
56.	2419P1707D1	[1]	PIN	KOBPIN
57.	2419P3687	[2]	PIN	KOBPIN
58.	2419P3415	[1]	PIN	KOBPIN
59.	2419T6440	[1]	PIN	KOBPIN Superseded by part number: 2419T7613
60.	2416T13056	[1]	BRACKET	KOBBRACKET
61.	2418T12469	[2]	PLATE	KOB150 x 50 x Th 12mm, 2-Ø16 Holes
62.	2418T17550	[2]	PLATE	KOBID 18 x OD 60 x Th 06mm
63.	ZS23C12040	[4]	SCREW,Hex Socket Head, M12 x 40mm	KOBM12x1.75x40mm
64.	2411T671D5	[2]	BOSS	KOBBOSS
65.	B16T0442D3	[2]	SHIM,150mm OD x 82mm ID x 1.2mm Thk	KOBID 82 x OD 150 x Th 1.2mm
66.	B16T0442D4	[2]	SHIM,82mm ID x 150mm OD x 1.6mm Thk	KOBID 82 x OD 150 x Th 1.6mm
67.	B16T0442D6	[2]	SHIM,150mm OD x 82mm ID x 2.3mm Thk	KOBID 82 x OD 150 x Th 2.3mm
68.	ZE13X16000	[2]	FLANGE	KOBClamp, Half -- (Incls. Capscrew & Lockwasher)
69.	B16T0442D62	[3]	SHIM,87mm ID x 140mm OD x 1.6mm Thk	KOBID 87 x OD 140 x Th 1.6mm
70.	ZW22K12000	[4]	LOCK WASHER	KOBID 12.2 x OD 17.8 x Th 2.5mm
71.	B16T0442D40	[1]	SHIM,92mm ID x 160mm OD x 0.9mm Thk	KOBID 92 x OD 160 x Th 0.9mm
72.	B16T0442D13	[1]	SHIM,160mm OD x 92mm ID x 1.2mm Thk	KOBID 92 x OD 160 x Th 1.2mm
73.	B16T0442D14	[1]	SHIM,160mm OD x 92mm ID x 1.6mm Thk	KOBID 92 x OD 160 x Th 1.6mm
74.	B16T0442D15	[1]	SHIM,160mm OD x 92mm ID x 2.3mm Thk	KOBID 92 x OD 160 x Th 2.3mm
75.	2432P2802	[1]	TYPE PLATE	KOBNAME PLATE Superseded by part number: 2432P2259
76.	2432P2803	[1]	TYPE PLATE	KOBNAME PLATE Superseded by part number: 2432P2260
81.	2418P28993	[1]	TUBE	KOBTUBE
82.	2418P28994	[1]	TUBE	KOBTUBE
83.	2418P28995	[1]	TUBE	KOBTUBE
84.	2418P28996	[1]	TUBE	KOBTUBE
85.	B16T0442D53	[1]	SHIM,92mm ID x 160mm OD x 0.5mm Thk	KOBID 92 x OD 160 x Th 0.5mm
86.	2444R1133D5	[4]	HOSE	KOB760mm Long (29-59/64 in)
87.	2444R1102D2	[1]	HOSE	KOBHOSE
88.	2436R767F2	[2]	VALVE	KOBASSY, SEE (C. P. M)
89.	2432R240F1	[2]	U-BRACKET	KOBBAND ASSY
89-1.	2438U914D1S24	[1]	U-BRACKET	KOBBAND
89-2.	2436R764S2	[1]	BAND PLATE, SUB	BAND PLATE, SUB
89-3.	ZW26X10000	[4]	LOCK WASHER	KOBID 10 x OD 18 x Th 2.5mm
89-4.	ZS11C10035	[2]	SCREW,Hex, M10 x 35mm, Cl 4.8	KOBCAPSCREW Superseded by part number: ZS18C10035
89-5.	ZS23C10025	[2]	SCREW,Hex Socket Head, M10 x 25mm	KOBM10x1.50x25mm Superseded by part number: ZS28C10025
89-6.	ZN16C10008	[2]	NUT	KOBM10x1.50mm Superseded by part number: ZN18C10008
90.	2432T2340	[2]	CLAMP	KOB
91.	ZA23F15006	[2]	HYD CONNECTOR	KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied)
92.	ZA23F15008	[2]	HYD CONNECTOR	KOB
93.	B16T0442D52	[3]	SHIM,82mm ID x 100mm OD x 0.5mm Thk	KOBID 82 x OD 150 x Th 0.5mm
94.	ZA33F10004	[2]	ELBOW	KOB
95.	ZD12P01400	[3]	O-RING	KOBID 13.80 ± 0.19 x OD 18mm
96.	ZD12P01800	[3]	O-RING	KOBID 17.8mm x OD 20.2mm
97.	ZD12P01100	[2]	O-RING	KOBID 10.8mm x OD 13.2mm
98.	ZS23C10060	[8]	SCREW,Hex Socket Head, M10 x 60mm	KOBM10x1.50x60mm
99.	ZW22K10000	[8]	LOCK WASHER	KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm
102.	B16T0442D39	[2]	SHIM,82mm ID x 150mm OD x 0.9mm Thk	KOBID 82 x OD 150 x Th 0.9mm
103.	B16T0442D76	[3]	SHIM,140mm OD x 87mm ID x 1.2mm Thk	KOBID 87 x OD 140 x Th 1.2mm
104.	B16T0442D77	[3]	SHIM,87mm ID x 140mm OD x 0.9mm Thk	KOBID 87 x OD 140 x Th 0.9mm
105.	B16T0442D78	[3]	SHIM,87mm ID x 140mm OD x 0.5mm Thk	KOBID 87 x OD 140 x Th 0.5mm
107.	2436U2822F1	[1]	VALVE	KOBASSY, SEE (C. P. M)
108.	2415P524	[1]	BAND ASSY
109.	2432T5529	[3]	CLAMP	KOB
110.	2432T5530	[3]	CLAMP	KOB
111.	2432T5531	[2]	CLAMP	KOBDouble -- 82x32x19mm Threaded M12
112.	2432T5532	[2]	CLAMP	KOBDouble -- 82x32x19mm Hole Only
113.	2432T5626	[1]	CLAMP	KOBDouble -- 98x38x22mm Threaded M12
114.	2432T5625	[1]	CLAMP	KOBDouble -- 98x38x22mm Hole Only
115.	2444Z3499	[1]	HYD CONNECTOR	KOB3/8"PF - M22x1.50 x 39mm Long
116.	2444Z3251	[1]	FITTING	KOB3/8"PF - M26x1.50 x 39mm Long
117.	ZA24F18008	[1]	HYD CONNECTOR	KOB
118.	2444T4609F1	[1]	HYD CONNECTOR	KOB
119.	ZF23E10006	[1]	HYD CONNECTOR	KOB
120.	ZA53B15000	[1]	TEE	KOB
121.	2418P28997	[1]	RIGID TUBE	KOBTUBE
122.	2418P28998	[1]	RIGID TUBE	KOBTUBE
123.	2418P28999	[1]	RIGID TUBE	KOB
124.	2444R892D10	[1]	HOSE	KOBHOSE
125.	2444R949D8	[1]	HOSE	KOBHOSE
126.	ZA23H15006	[1]	HYD CONNECTOR	KOB
127.	ZS13C12060	[4]	SCREW	KOBM12x1.75x60mm Superseded by part number: ZS18C12060
129.	ZS13C12045	[6]	SCREW	KOBM12x1.75x45mm Superseded by part number: ZS18C12045
135.	2432T4012	[1]	CLAMP	KOB
136.	2432T4013	[1]	CLAMP	KOB
139.	ZS13C10025	[6]	CAPSCREW	KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025
140.	ZS13C10035	[6]	SCREW	KOBM10x1.50x35mm Superseded by part number: ZS18C10035
141.	ZD12G03500	[1]	O-RING,34.40mm ID x 40.60mm OD x 3.10mm	KOBID 34.40 ± 0.33 x OD 40mm
142.	ZD12G03000	[2]	O-RING,29.40mm ID x 35.60mm OD x 3.10mm	KOBID 29.4 ± 0.29 x OD 35mm
143.	ZN13C10008	[4]	NUT	KOBM10x1.50mm Superseded by part number: ZN18C10008
211.	2444R950D1	[2]	HOSE	KOB
501.	2418P24254	[1]	TUBE	KOBTUBE
502.	2418P30490	[1]	TUBE	KOBTUBE
503.	2418P30491	[1]	TUBE	KOBTUBE
504.	2418P30492	[1]	TUBE	KOBTUBE
507.	2432T3993	[9]	CLAMP	KOBDouble Line -- 95x38x19mm Hole Only
508.	2432T3994	[9]	CLAMP	KOBDouble Line -- 95x38x19mm Threaded M12
509.	2432T5916	[2]	CLAMP	KOB
510.	2432T5917	[2]	CLAMP	KOB
511.	ZA23B18000	[2]	HYD CONNECTOR	KOB
512.	ZS13C12040	[14]	SCREW	KOBM12x1.75x40mm Superseded by part number: ZS18C12040
513.	2414Z199D025	[2]	PROTECTIVE SLEEVE	KOBHose -- 250mm Long (9-27/32 in)
