| . . | 24100J15097F5 | [1] | ARM ASSY, 2.94M | |
| 2. | 2438U1105F1 | [1] | CYLINDER | KOBRemarks: SEE (C. P. M) |
| 3. | 2406N1662F1 | [1] | LINK CONROD | KOBLINK, BUCKET |
| 3-8. | 2405T951 | [2] | BUSHING | KOB |
| 3-9. | 2405T1275 | [2] | BUSHING | KOB |
| 4. | 2406P4823D1 | [1] | LINK CONROD | KOBLINK, IDLER |
| 5. | 2406P4823D2 | [1] | LINK CONROD | KOBLINK, IDLER |
| 7. | 2418T12144 | [1] | RIGID TUBE | KOBTUBE |
| 8. | 2418T17376D2 | [1] | RIGID TUBE | KOBTUBE |
| 9. | 2444R1177D4 | [2] | FLEXIBLE HOSE | KOB1350mm Long (53-9/64 in) |
| 10. | 2419T3752 | [2] | PIN | KOB Superseded by part number: 2419T7605D1 |
| 11. | 2419P3381D1 | [1] | PIN | KOB Superseded by part number: 2419P4047D1 |
| 12. | 2419P3266D1 | [1] | PIN,80mm OD x 480mm L | KOB Superseded by part number: 2419P4044D1 |
| 13. | 2419P3331D1 | [1] | PIN | KOB Superseded by part number: 2419P4046D1 |
| 14. | 2419P2952 | [1] | PIN | KOB Superseded by part number: 2419P4040 |
| 15. | 2445R220D3 | [2] | SEAL,70mm ID x 85mm OD x 5mm Thk | KOBDust -- ID 70 x OD 85 x Th 5mm |
| 16. | 2445R220D4 | [10] | SEAL,78.7mm ID x 95mm OD x 5mm Thk | KOBDust -- ID 80 X OD 95 x Th 5mm Superseded by part number: 84499640 |
| 17. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 18. | 2432T1187 | [1] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 19. | 2420T4330D10 | [2] | SCREW,M16 x 2 x 140mm | KOBM16x2.0x140mm Superseded by part number: ZS18C16140 |
| 20. | 2420T4330D2 | [1] | SCREW,M16 x 2 x 150mm | KOBM16x2.0x150mm Superseded by part number: HS18C16150G1 |
| 22. | 2420T4330D9 | [1] | SCREW,M16 x 2 x 130mm | KOBM16x2.0x130mm Superseded by part number: HS18C16130G2 |
| 23. | ZS13C10070 | [8] | SCREW | KOBM10x1.50x70mm Superseded by part number: ZS18C10070 |
| 24. | ZS13C10055 | [1] | SCREW | KOBM10x1.50x55mm Superseded by part number: ZS18C10055 |
| 25. | ZN13C16013 | [8] | NUT | KOBM16x2.0mm |
| 26. | ZW22X10000 | [11] | LOCK WASHER | KOBID 10 x OD 18.4 x Th 2.5mm Superseded by part number: ZW26X10000 |
| 27. | ZG91S02000 | [5] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 28. | ZG91U02000 | [2] | LUBE NIPPLE | KOB90° x 1/8" PT |
| 29. | 2418T23987D2 | [2] | RING | KOBRetaining -- ID 105 ± 1.0 x OD 110 x Th 12mm |
| 30. | 2419T6002D6 | [2] | PIN,16mm OD x 102mm L | KOBOD 16 x 102mm Long |
| 31. | B16T0442D1 | [1] | SHIM,130mm OD x 72mm ID x 1.2mm Thk | KOBID 72 x OD 130 x Th 1.2mm |
| 32. | B16T0442D2 | [1] | SHIM,130mm OD x 72mm ID x 1.6mm Thk | KOBID 72 x OD 130 x Th 1.6mm |
| 33. | B16T0442D5 | [1] | SHIM,130mm OD x 72mm ID x 2.3mm Thk | KOBID 72 x OD 130 x Th 2.3mm |
| 34. | B16T0442D3 | [3] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOBID 82 x OD 150 x Th 1.2mm |
| 35. | B16T0442D4 | [3] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 36. | B16T0442D6 | [3] | SHIM,150mm OD x 82mm ID x 2.3mm Thk | KOBID 82 x OD 150 x Th 2.3mm |
| 37. | B16T0442D48 | [1] | SHIM,160mm OD x 87mm ID x 1.2mm Thk | KOBID 87 x OD 160 x Th 1.2mm |
| 38. | B16T0442D37 | [1] | SHIM,155mm OD x 87mm ID x 1.6mm Thk | KOBID 87 x OD 155 x Th 1.6mm |
| 39. | B16T0442D50 | [1] | SHIM,160mm OD x 87mm ID x 2.3mm Thk | KOBID 87 x OD 160 x Th 2.3mm |
| 49. | B16T0442D44 | [1] | SHIM,72mm ID x 130mm OD x 0.9mm Thk | KOBID 72 x OD 130 x Th 0.9mm |
| 50. | B16T0442D57 | [1] | SHIM,72mm ID x 130mm OD x 0.5mm Thk | KOBID 72 x OD 130 x Th 0.5mm |
| 51. | B16T0442D39 | [3] | SHIM,82mm ID x 150mm OD x 0.9mm Thk | KOBID 82 x OD 150 x Th 0.9mm |
| 52. | B16T0442D52 | [3] | SHIM,82mm ID x 100mm OD x 0.5mm Thk | KOBID 82 x OD 150 x Th 0.5mm |
| 53. | B16T0442D77 | [1] | SHIM,87mm ID x 140mm OD x 0.9mm Thk | KOBID 87 x OD 140 x Th 0.9mm |
| 54. | B16T0442D78 | [1] | SHIM,87mm ID x 140mm OD x 0.5mm Thk | KOBID 87 x OD 140 x Th 0.5mm |
| 55. | B16T0442D79 | [1] | SHIM,130mm OD x 82mm ID x 0.5mm Thk | KOBID 82 x OD 130 x Th 0.5mm |
| 103. | ZX56T16160 | [2] | FLEXIBLE HOSE | KOBHOSE |
| 105. | ZC26X35016 | [8] | CLAMP | KOBSingle Line -- 85x44x38mm (Ø35mm) |
| 109. | ZS13C14060 | [8] | SCREW | KOBM14x2.0x60mm Superseded by part number: ZS18C14060 |
| 111. | ZW22X14000 | [8] | LOCK WASHER | KOBID 14 x OD 24.5 x Th 3.5mm Superseded by part number: ZW26X14000 |
| 114. | 2444T2406 | [2] | PLUG | KOBCap -- 1-5/16" 12UNF |
| 200. | 2411J5045D5F1 | [1] | ARM | |
| 200-24. | 2405T1274 | [2] | BUSHING,80mm ID x 95mm OD x 93mm L | KOB Superseded by part number: 2405T1902 |
| 200-25. | B05T0041C2 | [2] | BUSHING | KOB |
| 200-26. | B05T0009C2 | [2] | BUSHING | KOB |
| 200-33. | 2418T12187D10 | [2] | PLATE | |
| 200-34. | 2416T26845 | [4] | BLOCK, TAPPED | |
| 200-35. | 2416T21120D3 | [2] | LINK BLOCK | KOBBLOCK, TAPPED |
| 200-36. | 2411T763 | [2] | BLOCK | KOBPLATE |
| 200-37. | 2416T9878D5 | [2] | CONNECTING BLOCK | KOBBLOCK, TAPPED |
| 201. | 2418P28981D1 | [1] | TUBE | KOB |
| 202. | 2418P28981D2 | [1] | TUBE | KOB |
| 203. | 2418P24292D4 | [1] | RIGID TUBE | KOBTUBE |
| 204. | 2418P24292D3 | [1] | RIGID TUBE | KOBTUBE |
| 205. | 2418P29039 | [1] | TUBE | TUBE |
| 206. | 2418P29040 | [1] | TUBE | TUBE |
| 207. | 2418P29041D1 | [1] | TUBE | TUBE |
| 208. | 2418P29041D2 | [1] | TUBE | TUBE |
| 216. | ZC36X18011 | [2] | CLAMP | KOB |
| 218. | 2420T4384 | [4] | PLUG | KOB |
| 219. | 24100P1005F1 | [2] | VALVE | KOBSELECTOR Superseded by part number: 24100P1005F3 |
| 219-1. | 2436P229 | [1] | VALVE BODY | KOBBODY, VALVE |
| 219-2. | 2436T303 | [1] | VALVE | KOB |
| 219-3. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 219-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 219-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 219-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 219-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 219-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 219-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 219-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 220. | 2444T2453D1 | [2] | CONNECTOR | |
| 221. | 2444Z2093 | [4] | HYD CONNECTOR | KOBCONNECTOR |
| 222. | 2444Z2225 | [4] | HYD CONNECTOR | KOBCONNECTOR |
| 223. | ZA53B18000 | [2] | TEE | KOB |
| 224. | ZD12P02400 | [6] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 226. | ZS13C10045 | [2] | SCREW | KOBM10x1.50x45mm Superseded by part number: ZS18C10045 |
