神钢零件查询(BREAKER) - NIBBLER AND BREAKER ATTACHMENT - SK220LC EXCAVATORS (9/04-) (011-50) - Frame Assy, Upp Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
489 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J13834F7 | [1] | FRAME ASSY, UPP | |
| . . | 24100J13834F8 | [1] | FRAME ASSY, UPP | |
| . . | 24100J13834F9 | [1] | FRAME ASSY, UPP | |
| . . | 24100J13834F11 | [1] | FRAME ASSY, UPP | |
| 5. | 2414T4703F1 | [1] | COVER | KOBASSY |
| 5-1. | 2414P7583 | [1] | COVER | |
| 5-2. | 2427Z1343 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 6. | 24100J11720F4 | [1] | HYDRAULIC MOTOR | KOBMOTOR ASSY, SWING, Remarks: P.025-01 |
| 7. | 2420R561D1 | [1] | DIPSTICK | KOBDIP STIC |
| 8. | 2420P1519D1 | [1] | PIPE | KOB |
| 10. | ZS13C10025 | [7] | CAPSCREW | KOBM10x1.50x25mm Superseded by part number: ZS18C10025 |
| 11. | ZS23C20065 | [16] | SCREW,Hex Socket Head, M20 x 65mm | KOBM20x2.5x65mm |
| 12. | ZS13C20120 | [30] | SCREW | KOBM20x2.50x120mm |
| 13. | 2420Z1201 | [3] | SCREW | KOBBOLT, REAMER |
| 14. | ZW13H1000 | [7] | WASHER | |
| 16. | ZW13H20000 | [33] | WASHER | KOBID 20 x OD 40 x Th 4.5mm |
| 18. | 2427Z1402 | [1] | INSULATION | KOBSOUND |
| 19. | 2427Z1401 | [1] | INSULATION | KOBSOUND |
| 20. | 2427T919D2 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 21. | 2427T917D2 | [2] | FOAM INSULATION | KOBINSULATION, SOUND |
| 22. | 2427Z1403D2 | [1] | INSULATION, SOUND | |
| 23. | 2427Z1403D1 | [1] | INSULATION, SOUND | |
| 24. | 2479Z2216 | [1] | INSULATOR | KOB |
| 25. | 2479Z2407 | [1] | INSULATOR | KOB |
| 26. | 2479Z2218 | [1] | INSULATOR | KOB |
| 28. | 2420T6786 | [11] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher) Superseded by part number: ZM32C12025 |
| 29. | 2418T12125 | [1] | PLATE | KOB Superseded by part number: YN52F01159P1 |
| 30. | 2416Z434 | [1] | PACKING | KOBRubber |
| 31. | 2414T4820F2 | [1] | COVER ASSY, Remarks: F7, F8 ONLY | |
| 31-2. | 2427Z1344 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 31-3. | 2416Z263D2 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 31-4. | 2414P8769 | [1] | COVER | |
| 33. | 24100P3750F1 | [1] | STAY | KOBASSY |
| 33-1. | 2416P18523 | [1] | STAY | KOB |
| 33-2. | 2432T411302 | [1] | CLAMP | |
| 33-3. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 33-4. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 34. | 2456R351 | [1] | MIRROR | KOB |
| 35. | 2445T290 | [1] | SEAL | KOBDUST Superseded by part number: YN52F01161P1 |
| 36. | 2416T28046 | [1] | BRACKET | BRACKET |
| 40. | 2414T4934F2 | [1] | COVER ASSY, Remarks: (F9, F10 ONLY) | |
| 40-2. | 2427Z1454 | [1] | INSULATION, SOUND | |
| 40-3. | 2416Z263D2 | [1] | FOAM INSULATION | KOBSHEET, RUBBER |
| 40-4. | 2414P8764 | [1] | COVER | |
| 42. | 2422J3754D6 | [1] | FRAME, UPP, Remarks: P. 014-50A (F7 ONLY) | |
| . . | 2422J3754D7 | [1] | FRAME, UPP, Remarks: (F8 ONLY) | |
| . . | 2422J3754D8 | [1] | FRAME, UPP, Remarks: (F9 ONLY) | |
| . . | 2422J3754D10 | [1] | FRAME, UPP, Remarks: (F11 ONLY) | |
| 42-1. | 2405T1260 | [2] | BUSHING | KOB |
| 42-2. | 2414T2795 | [1] | COVER | KOB |
| 42-3. | ZS83C20020 | [2] | SCREW | KOBSet -- M20x2.50x20mm |
