| . . | 24100J15791F2 | [1] | REMOTE-CONTROL ASSY | |
| 2. | 2444Z2336 | [2] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 4. | ZH32X04000 | [8] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 5. | 2436U1142F1 | [1] | PILOT VALVE | KOBVALVE, PILOT, Remarks: SEE(C. P. M) |
| 9. | 2523C10016 | [1] | CAPSCREW | |
| 10. | ZW22K10000 | [1] | LOCK WASHER | KOBLock -- ID 10.2 x OD 15.7 x Th 2.5mm |
| 11. | ZH52X04000 | [1] | TEE,30 Degree Fl, Male, PF 1/4" x 1/4" x 1/4", O-Ring | KOB1/4" PF (Incls. O-Ring 237-6004) |
| 12. | 2420R1184D035 | [1] | HOSE | HOSE |
| 14. | 2420R1182D210 | [1] | FLEXIBLE HOSE | KOBHOSE Superseded by part number: HX21E04210DX |
| 15. | 2420R1182D230 | [1] | HOSE ASSY. | KOBHOSE Superseded by part number: 2420R349D230 |
| 16. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 17. | 2436P231F1 | [1] | VALVE PRESSURE RELIE | KOBVALVE, SELECTOR |
| 17-1. | 2436P232 | [1] | BODY, VALVE | |
| 17-2. | 2436T305 | [1] | VALVE | |
| 17-3. | 2418T8945D3 | [1] | ID 30 x OD 44 x Th 3.2mm | ID 30 x OD 44 x Th 3.2mm |
| 17-4. | ZR16X03000 | [1] | SNAP RING | KOBSNAP RING |
| 17-5. | 2420Z922 | [1] | CAPSCREW | CAPSCREW |
| 17-6. | ZD11G03000 | [2] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOB |
| 17-7. | ZD12G02500 | [1] | O-RING,24.40mm ID x 30.60mm OD x 3.10mm | KOBID 24.4 ± 0.25 x OD 30mm |
| 17-8. | ZD85G02500 | [1] | BACK-UP RING | KOBRing, Back-Up -- ID 25 x OD 30 x Th 1.25mm |
| 17-9. | ZD12G03000 | [1] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 17-10. | ZD75G03000 | [1] | BACK-UP RING | KOBRING, BACK UP |
| 20. | 2420R1182D045 | [2] | HOSE | HOSE |
| 21. | 2420R1182D110 | [1] | HOSE | KOB1100mm Long (43-19/64 in) Superseded by part number: 2420R349D110 |
| 22. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 23. | 2420R1182D025 | [1] | HOSE | HOSE |
| 24. | 2420R1182D090 | [1] | HOSE | HOSE |
| 27. | 2444Z2335 | [1] | CONNECTION | KOBCONNECTOR |
| 30. | ZS18C10020 | [1] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 35. | 2444T2505 | [1] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 36. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 39. | 2420R1182D100 | [1] | HOSE | KOB |
| 47. | 2444Z4081 | [1] | ELBOW | KOB(WITH FILTER) Superseded by part number: HH35X04004G3 |
| 48. | 2444T2592 | [1] | TEE | KOB3/8" PF - 1/4" PF (No O-Ring supplied) |
| 49. | 2406P5346 | [1] | PEDAL | KOB |
| 50. | 2414P8766 | [1] | TRIM | KOB |
| 53. | 244422461 | [1] | TEE | |
| 54. | 2444Z3841 | [1] | TEE | KOB |
| 55. | ZS18C08018 | [2] | CAPSCREW,Hex, M8 x 18mm | KOBM08x1.25x16mm Superseded by part number: ZS18C08020 |
| 56. | ZS18C08025 | [2] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 57. | ZW26X08000 | [4] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 58. | ZW26X10000 | [1] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 60. | 24100P2919F4 | [1] | LOCK | KOBASSY |
| 60-2. | 2406P4095 | [1] | LOCK | KOBLEVER |
| 60-3. | 2417T533 | [1] | SPRING | KOB |
| 60-4. | 2419T3784D1 | [1] | PIN | KOB |
| 60-5. | ZW16X12000 | [1] | WASHER | KOBID 12 x OD 24 x Th 2.3mm |
| 60-6. | ZP16D04022 | [1] | PIN, SPLIT | |
| 60-9. | 2416P18650D1 | [1] | SUPPORT | KOB |
| 61. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 63. | 24100J15271F1 | [1] | REMOTE CONTROL ASSY, Remarks: P.161-50 | |
