斗山零件查询ENGINE TIMING SOLAR 330LC-V Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
839 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
65.04401-0010K
|
[1] |
CAM SHAFT
|
65.04401-0010L
|
| 1. |
65.04401-0010L
|
[1] |
CAM SHAFT
|
|
| 10. |
65.04506-0007
|
[1] |
PIN;IDLE GEAR
|
|
| 10. |
65.04506-0033
|
[1] |
PIN;IDLE GEAR
|
|
| 12. |
65.90720-0018
|
[1] |
WASHER;THRUST
|
|
| 14. |
06.01914-3225
|
[2] |
BOLT;HEX. M10X70
|
|
| 14. |
06.01015-7220
|
[2] |
BOLT;HEX
|
06.01015-9220
|
| 14. |
06.01015-9220
|
[2] |
BOLT;HEX
|
|
| 15. |
06.16731-2108
|
[2] |
WASHER;SPRING
|
|
| 16. |
65.04101-0044
|
[6] |
VALVE;EXHAUST
|
|
| 17. |
65.04101-0043
|
[6] |
VALVE;INTAKE
|
|
| 18. |
65.04102-6004
|
[6] |
SPRING VALVE ASS'Y
|
65.04102-6004A
|
| 18. |
65.04102-6004A
|
[6] |
SPRING VALVE ASS'Y
|
|
| 19. |
65.04102-0002
|
[1] |
SPRING;VALVE(INNER)
|
|
| 19. |
65.04102-0002A
|
[1] |
SPRING;VALVE(INNER)
|
|
| 2. |
65.98112-0038
|
[1] |
FLANGE
|
|
| 20. |
65.04102-0066
|
[6] |
SPRING;VALVE(OUTER)
|
|
| 21. |
65.04102-0066
|
[6] |
SPRING;VALVE(OUTER)
|
|
| 22. |
65.04103-0014
|
[12] |
RETAINER;VALVE SPRING
|
|
| 23. |
65.04104-0007
|
[24] |
COTTER;VALVE
|
|
| 24. |
65.04902-0010
|
[12] |
SEAL;VALVE STEM
|
|
| 25. |
65.04103-0011
|
[12] |
SEAT;VALVE SPRING
|
65.04103-0078
|
| 25. |
65.04103-0078
|
[12] |
SEAT;VALVE SPRING
|
|
| 26. |
65.04200-6027A
|
[2] |
ROCKER ARM & SHAFT ASS'Y(27~33)
|
65.04200-6027C
|
| 26. |
65.04200-6027C
|
[2] |
R/ARM & SHAFT ASS'Y
|
|
| 27. |
65.04203-5010
|
[1] |
SHAFT;ROCKER ARM
|
|
| 28. |
65.97601-0104
|
[2] |
SPRING;ROCKER ARM SHAFT
|
|
| 29. |
65.04201-5014D
|
[6] |
ROCKER ARM ASS'Y
|
65.04201-5014E
|
| 29. |
65.04201-5014E
|
[6] |
ROCKER ARM ASS'Y
|
|
| 3. |
65.90001-6003
|
[2] |
BOLT ASS`Y M6X14
|
|
| 32. |
65.04205-0003
|
[6] |
BOLT;ADJUSTING M10X1.0
|
|
| 33. |
65.90501-0003
|
[6] |
. NUT
|
|
| 34. |
65.04202-0014A
|
[3] |
BRACKET;ROCKER ARM
|
|
| 35. |
06.16731-2108
|
[6] |
WASHER;SPRING
|
|
| 36. |
06.01013-9221
|
[6] |
BOLT;HEX. M10X80
|
|
| 37. |
65.97601-0053
|
[2] |
SPRING;CONICAL
|
|
| 38. |
65.90710-0039
|
[2] |
WASHER;ROCKER ARM
|
|
| 39. |
06.29010-0120
|
[2] |
. RING;SNAP
|
|
| 4. |
65.04501-0007A
|
[1] |
GEAR;CAMSHAFT
|
|
| 40. |
06.15010-2311
|
[3] |
WASHER
|
|
| 41. |
06.01283-7112
|
[3] |
BOLT;HEX. M8X18
|
|
| 42. |
65.04301-0006
|
[12] |
TAPPET
|
|
| 43. |
65.04302-5011
|
[12] |
ROD;PUSH
|
|
| 5. |
06.22022-1014
|
[1] |
PIN;DOWEL
|
|
| 6. |
06.01913-3119
|
[4] |
BOLT ASS`Y M8X40
|
|
| 7. |
65.04505-5015
|
[1] |
IDLE GEAR ASS'Y
|
|
| 7. |
65.04505-5016
|
[1] |
IDLE GEAR ASS'Y
|
|
| 8. |
65.04505-0009
|
[1] |
IDLE GEAR
|
|
| 8. |
65.04505-0033
|
[1] |
GEAR;IDLE
|
|
| 9. |
65.04507-0003
|
[1] |
BEARING;IDLE GEAR
|
|
| 9. |
65.04507-0004
|
[1] |
BUSH;IDLE GEAR
|
|
