现代零件查询R220LC-7(IND,EXPORT) SWING REDUCTION GEAR (TYPE2,TYPE3)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
303 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
@
|
[1] |
SWING MOTOR ASSY
|
|
| -2. |
39N6-12100
|
[1] |
SWING REDUCTION GEAR
|
|
| 1. |
39Q6-12110
|
[1] |
GEAR-RING
|
|
| 2. |
39Q6-12121
|
[1] |
SHAFT-DRIVE
|
|
| 3. |
39Q6-12130
|
[1] |
BEARING-TAPER.MAIN
|
|
| 4. |
39Q6-12140
|
[1] |
BEARING-TAPER
|
|
| 5. |
39Q6-12150
|
[1] |
NUT-RING
|
|
| 6. |
39Q6-12161
|
[1] |
PLATE-LOCK
|
|
| 7. |
S017-120166
|
[4] |
BOLT-HEX
|
|
| 8. |
39Q6-12171
|
[1] |
CASING
|
|
| 9. |
S109-100306
|
[10] |
BOLT-SOCKET
|
|
| 10. |
39Q6-12190
|
[1] |
CARRIER 2
|
|
| 11. |
39Q6-12200
|
[3] |
GEAR-PLANETARY 2
|
|
| 12. |
39Q6-12210
|
[6] |
BEARING-NEEDLE 2
|
|
| 13. |
39Q6-12220
|
[6] |
WASHER-THRUST 2
|
|
| 14. |
39Q6-12230
|
[3] |
PIN-CARRIER 2
|
|
| 15. |
S472-800364
|
[3] |
PIN-SPRING
|
|
| 16. |
39Q6-12240
|
[1] |
GEAR-SUN 2
|
|
| 17. |
39Q6-12260
|
[1] |
CARRIER 1
|
|
| 18. |
39Q6-12271
|
[3] |
GEAR-PLANETARY 1
|
|
| 19. |
39Q6-12280
|
[3] |
BEARING-NEEDLE 1
|
|
| 20. |
39Q6-12290
|
[3] |
WASHER-THRUST 1,UPP
|
|
| 21. |
39Q6-12300
|
[3] |
WASHER-THRUST 1,LOW
|
|
| 22. |
39Q6-12310
|
[3] |
PIN-CARRIER 1
|
|
| 23. |
S472-600364
|
[3] |
PIN-SPRING
|
|
| 24. |
39Q6-12320
|
[1] |
GEAR-SUN 1
|
|
| 25. |
39Q6-12330
|
[2] |
PLATE-THRUST
|
|
| 26. |
39Q6-12340
|
[1] |
SLEEVE
|
|
| 27. |
S631-120001
|
[1] |
O-RING
|
|
| 28. |
39Q6-12350
|
[1] |
SEAL-OIL
|
|
| 29. |
39Q6-41450
|
[2] |
PIN-PARALLEL
|
|
| 30. |
S109-16045D
|
[12] |
BOLT-SOCKET
|
|
| 31. |
39Q6-12360
|
[1] |
NAME PLATE
|
|
| 32. |
39Q6-41800
|
[2] |
RIVET
|
|
| 33. |
P220-430204
|
[1] |
PLUG-HEX
|
|
| -1. |
@
|
[1] |
SWING MOTOR UNIT
|
|
| K1. |
39Q6-12180
|
[1] |
CARRIER ASSY KIT 1
|
|
| K2. |
39Q6-12250
|
[1] |
CARRIER ASSY KIT 2
|
|
