| . . | LC06H00001F2 | [1] | CONTROL LINES, MAIN | |
| 1. | 2420R349D035 | [1] | HOSE | KOB350mm Long (13-49/64 in) |
| 2. | ZH22X04006 | [11] | HYD CONNECTOR | KOB(Incls. O-Ring 237-6006) |
| 3. | ZH22X06000 | [8] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) (PF3/8) |
| 4. | ZH32X04000 | [6] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 5. | ZH32X04006 | [7] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 6. | ZH32X06000 | [4] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 7. | HH55Q06006G1 | [5] | TEE | KOB3/8" PF (Incls. O-Ring ZD12P01400) |
| 9. | 2444Z2336 | [2] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 11. | YN06H01017P1 | [1] | HYD CONNECTOR | KOB3/8" PF - 3/8" PF x 35mm Long (Incls. O-Rings ZD12P01400) |
| 12. | LC52S00001P2 | [1] | PRESSURE SWITCH | KOB(L.P.) Superseded by part number: LC52S00001P3 |
| 12-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 13. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 14. | 2420R349D075 | [1] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 15. | 2420R349D042 | [1] | HOSE ASSY. | KOBPF 1/4, 420mm Long (16-1/2 in) Superseded by part number: 2420R349D045 |
| 16. | 2444R1120D090 | [2] | HOSE | KOB |
| 17. | 2444R1120D030 | [1] | HOSE | KOB300mm Long (11-13/16 in) |
| 18. | 2444R1120D055 | [1] | HOSE | KOB550mm Long (21-21/32 in) |
| 19. | 2420R349D065 | [1] | HOSE,650.00 mm | KOB650mm Long (25-1/2 in) Superseded by part number: HX21E04065DX |
| 20. | 2444Z2891 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 21. | 2444Z4244 | [1] | HYD CONNECTOR | KOBCONNECTOR |
| 22. | YN68H01004P1 | [1] | HYD CONNECTOR | KOB |
| 23. | HH35X04006G2 | [1] | ELBOW | KOB90° -- 1/4"PFx3/8"PFx42.5mm Long (Incls. O-Ring ZD12P01400) |
| 24. | HH25R06006GE | [1] | ELEC CONNECTOR | KOB |
| 25. | PY01P01043D4 | [2] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 26. | 2418R676D1 | [2] | TUBE | KOBID 10.7 x OD 14.1 x 100mm Long (3-15/16 in) |
| 27. | YN64H01022P1 | [1] | CONNECTION | KOB |
| 28. | ZS18C10025 | [1] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 29. | ZW16H10000 | [1] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 30. | 2444T2505 | [1] | HYD CONNECTOR | KOB1/4" PF - 3/8" PF x 35mm Long (Incls. O-Ring ZD12P01400) |
| 31. | ZX23M04046 | [1] | HOSE | KOB |
