凯斯零件查询(LB324P) - BALER (9/12-) (55.820.020) - ELECTRICITY CUTTER STATUS - D056 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
125 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47471074
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
84391774
|
[1] |
SENSOR
|
ZED
B010 - Sensor Cutter Status
|
| 3. |
920516
|
[1] |
GUIDE
|
ZED
|
| 4. |
86590413
|
[1] |
BASE,15.87mm W x 22.22mm OAL x 9.9mm Thk
|
ZED
|
| 5. |
445394
|
[1] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 6. |
86566990
|
[1] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 7. |
82013031
|
[7] |
CABLE TIE,193mm L
|
BAS
Superseded by part number: 87718512
|
