神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (01-030[05]) - HARNESS ASSY, UPP (EXTRA, EXTRA + NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
657 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC13E00006F4 | [1] | HARNESS ASSY, UPP | |
| 2. | 2486R89D4 | [1] | CABLE | KOB |
| 3. | YN13E01053D2 | [1] | CABLE | KOB430mm Long (16-59/64 in) (Battery) |
| 4. | YN13E01118P1 | [1] | CABLE | KOB |
| 5. | LC13E01018P1 | [1] | WIRE HARNESS | KOB |
| 6. | LE13E01006P1 | [1] | HARNESS | KOB100mm Long (3-15/16 in) |
| 7. | ZW26X08000 | [5] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 8. | ZN18C08007 | [4] | NUT | KOBM08x1.25mm |
| 9. | ZM11C08016 | [1] | BOLT | KOBM08x1.25x16mm (Incls. Lockwasher) |
| 10. | LC13E01002D3 | [1] | GROMMET | KOB |
| 11. | PY01P01043D3 | [15] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 12. | 2432R233D2 | [6] | CLIP | KOB37x12x40mm |
| 13. | 2420Z1330 | [1] | GROMMET | KOB |
| 14. | 2427Z1594D015 | [1] | TRIM PANEL | KOB |
| 15. | ZS18C08016 | [1] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 16. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 17. | 2420R372D19 | [1] | GROMMET | KOB |
| 18. | YN03E01001D5 | [1] | CLIP | KOB195mm Long (7-43/64 in) -- Black |
| 19. | LC13E01035P3 | [1] | HARNESS | KOB |
| 20. | YN13E01209D3 | [1] | HARNESS | KOB |
| 22. | LC13E01049P1 | [1] | HARNESS | KOB |
