神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (02-017) - CONNECTOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
544 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN43H00004F1 | [1] | HYD CONNECTOR | KOBAssembly |
| 1. | 2444P1744D3 | [1] | HYD CONNECTOR | KOB1-5/16" 12UNF x 1-1/4" PF (No O-Ring supplied) |
| 2. | 2444T2406 | [1] | PLUG | KOBCap -- 1-5/16" 12UNF |
| 3. | ZD12P03800 | [1] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| . . | YN43H00005F1 | [1] | HYD CONNECTOR | KOBCONNECTOR ASSY (TOKU, KRUPP) |
| 1. | 2444P1745D4 | [1] | HYD CONNECTOR | KOB |
| 2. | 2420Z1228D5 | [1] | PLUG | KOB |
| . . | YN43H00006F1 | [1] | HYD CONNECTOR | KOBASSY (NIBBLER) |
| 1. | YN43H01006P1 | [1] | HYD CONNECTOR | KOB |
| 2. | 2444T1329D6 | [1] | PLUG | KOB Superseded by part number: ZF83H35000 |
