凯斯零件查询(LB324P) - BALER (9/12-) (71.460.100) - CENTRAL GREASING, PACKER ARMS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
443 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84341250
|
[1] |
DIVIDER
|
ZED
Incl 2 - 10
|
| 2. |
84379937
|
[1] |
DIVIDER
|
ZED
8/8
|
| 3. |
84807301
|
[2] |
END FITTING
|
ZED
|
| 4. |
84807292
|
[6] |
HYD CONNECTOR
|
ZED
Superseded by part number: 2928867
|
| 5. |
84388052
|
[14] |
SCREW ON COUPLING
|
ZED
Superseded by part number: 1431140, 1431139
|
| 6. |
84388050
|
[1] |
HOSE
|
ZED
L=2.05M Superseded by part number: 84807290
|
| 7. |
84379944
|
[1] |
HOSE
|
ZED
L=7.8M Superseded by part number: 84807289
|
| 8. |
84807304
|
[1] |
LUBE NIPPLE
|
ZED
|
| 9. |
84807375
|
[1] |
NIPPLE
|
ZED
|
| 10. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Fitting Incl in 1
|
| 11. |
120056
|
[2] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
, Serial Range: -C084
|
| 11. |
412364
|
[2] |
CARRIAGE BOLT,M6 x 1.0 x 56.6mm, Cl 8.8
|
ZED
, Start Serial: D085
|
| 12. |
322357
|
[5] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 13. |
412152
|
[5] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 14. |
84807242
|
[2] |
NIPPLE
|
ZED
Superseded by part number: 84807377
|
| 15. |
84449335
|
[7] |
CABLE TIE,346mm L
|
ZED
|
| 16. |
84807376
|
[3] |
NIPPLE
|
ZED
|
| 17. |
9507815
|
[1] |
CONDUIT
|
CUR
|
| 18. |
84814948
|
[3] |
SUPPORT
|
ZED
|
| 19. |
86512441
|
[3] |
CARRIAGE BOLT,Rnd Head, M6 x 1 x 36.6mm, Cl 8.8
|
GI
|
| 20. |
84807377
|
[3] |
COUPLING
|
ZED
|
| 21. |
86566990
|
[16] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
