| . . | YT03H00034F4 | [1] | HYD LINES, UPP | |
| 1. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 1-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 2. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 3. | ZH22X08000 | [4] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 3-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 4. | 2444Z3713 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 4-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 5. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 7. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 8. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 8-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 9. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 10. | LE03H01213P1 | [1] | TEE | KOB |
| 10-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 11. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 13. | YT32H01030P1 | [2] | BUSHING | KOB |
| 15. | YT03H01022P1 | [1] | CLAMP | KOB |
| 16. | YT03H01049P1 | [1] | BRACKET | |
| 17. | ZX35M04030 | [1] | HOSE | KOB300mm Long (11-13/16 in) |
| 22. | YT03H01018P1 | [1] | BOLT | KOB |
| 23. | YT03H01019P1 | [2] | BUSHING | KOB Superseded by part number: YN03H01075P1 |
| 24. | ZW16H12000 | [1] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 25. | ZN18C12010 | [5] | NUT | KOBM12x1.75mm |
| 26. | 2414Z199D045 | [2] | PROTECTIVE SLEEVE | KOBHOSE |
| 27. | YN20M01046D2 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1200.00mm | KOBProtective Plastic |
| 28. | ZH32X06008 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 28-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 30. | ZX35M06050 | [1] | HOSE | KOB500mm Long (19-11/16 in) |
| 31. | ZX35M06058 | [1] | HOSE ASSY. | KOB580mm Long (22-53/64 in) Superseded by part number: ZX35M06060 |
| 32. | ZX45M08155 | [1] | HOSE | KOB1550mm Long (61 in) |
| 33. | ZW16H10000 | [6] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 34. | ZS18C10060 | [2] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 35. | ZN18C10008 | [2] | NUT | KOBM10x1.50mm |
| 36. | LE03H01212D7 | [2] | TUBE | |
| 38. | YT03H01050D2 | [1] | HOSE | KOBHOSE |
| 39. | YT03H01050D3 | [1] | HOSE | KOBHOSE |
| 40. | 2444R596D3 | [1] | ELBOW | KOB90° -- 1/2" PF |
| 41. | YR03H01178P1 | [1] | BLOCK | KOBBLOCK |
| 42. | HH55Q08008G3 | [1] | TEE,PF 1/2" x PF 1/2", O-Ring | KOB(PF 1/2) (Incls. O-Ring ZD12P01800) |
| 43. | HH35R08006G1 | [1] | ELBOW | KOBELBOW |
| 44. | LC52S00012P1 | [1] | SENSOR | KOBPressure (High Pressure) (replaced by LS52S00015P1) Superseded by part number: YY52S00033F1 |
| 44. | LS52S00015P1 | [2] | SENSOR | KOB(New part #) (Added by SB S030-41-K003) |
| 44-0. | YY52S00033F1 | [1] | PRESSURE SWITCH | KOBKit Includes Ref 44 - 44-3 (Refer to SB S030-41-K003) |
| 44-1. | LS30H01024P1 | [1] | HYD CONNECTOR | SM(Added with new part # press switch) |
| 44-2. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 44-3. | YT42H01128P1 | [1] | 90 ELBOW | KOB(Added with new part # press switch) |
