| . . | YT03H00032F9 | [1] | HYD LINES, UPP | |
| 1. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 1-1. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 2. | ZH22X04000 | [1] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 3. | ZH22X08000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 3-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 4. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 5. | ZH32X08000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 6. | HH55Q04004G1 | [1] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 7. | LE03H01213P1 | [1] | TEE | KOB |
| 7-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 8. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 9. | ZX35M04030 | [1] | HOSE | KOB300mm Long (11-13/16 in) |
| 11. | ZX25M08160 | [1] | HOSE | KOB1600mm Long (63 in) |
| 12. | ZS18C12070 | [1] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 13. | YT03H01019P1 | [2] | BUSHING | KOB Superseded by part number: YN03H01075P1 |
| 14. | ZW16H12000 | [2] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 15. | 2418Z1333D5 | [2] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 400mm Length | KOB |
| 16. | YN20M01046D2 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1200.00mm | KOBProtective Plastic |
| 17. | YT03H01021P1 | [2] | CLAMP | KOB |
| 18. | ZX25M08180 | [1] | HOSE | KOB1800mm Long (70-7/8 in) |
| 19. | YN20M01046D1 | [2] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 600.00mm | KOBProtective Plastic |
| 20. | ZX45M08155 | [1] | HOSE | KOB1550mm Long (61 in) |
| 21. | ZX35M06050 | [1] | HOSE | KOB500mm Long (19-11/16 in) |
| 22. | ZX35M06058 | [1] | HOSE ASSY. | KOB580mm Long (22-53/64 in) Superseded by part number: ZX35M06060 |
| 23. | 2444Z3713 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 23-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 24. | 2444Z3715 | [2] | 90 ELBOW | KOB90° -- 1/2" PF x 56mm Long (Incls. O-Ring ZD12P01800) |
| 24-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 25. | YR03H01125P1 | [2] | HYD CONNECTOR | KOB |
| 25-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 26. | ZH32X06008 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 26-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 27. | 2414Z199D100 | [2] | PROTECTIVE SLEEVE | KOBHose -- 1000mm Long (39-3/8 in) |
| 28. | ZN18C12010 | [1] | NUT | KOBM12x1.75mm |
| 34. | HH55Q08008G3 | [1] | TEE,PF 1/2" x PF 1/2", O-Ring | KOB(PF 1/2) (Incls. O-Ring ZD12P01800) |
| 35. | HH35R08006G1 | [1] | ELBOW | KOB |
| 36. | LC52S00012P1 | [1] | SENSOR | KOBPressure (High Pressure) (replaced by LS52S00015P1) Superseded by part number: YY52S00033F1 |
| 36. | LS52S00015P1 | [2] | SENSOR | KOB(New part #) (Added by SB S030-41-K003) |
| 36-0. | YY52S00033F1 | [1] | PRESSURE SWITCH | KOBKit Includes Ref 36 - 36-3 (Refer to SB S030-41-K003) |
| 36-1. | LS30H01024P1 | [1] | HYD CONNECTOR | SM(Added with new part # press switch) |
| 36-2. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 36-3. | YT42H01128P1 | [1] | 90 ELBOW | KOB(Added with new part # press switch) |
