| . . | YT32H00009F2 | [1] | HYD LINES, RETURN | |
| 1. | YR32H01022P1 | [1] | TUBE | KOB |
| 2. | YR32H01020P1 | [1] | TUBE | KOB |
| 4. | ZX22M06170 | [1] | HOSE | KOB1700mm Long (66-59/64 in) |
| 5. | 2444R1119D045 | [1] | HOSE | KOB450mm Long (17-23/32 in) Superseded by part number: 2444R1119D046 |
| 6. | ZX32M08175 | [1] | HOSE | KOB1750mm Long (68-57/64 in) |
| 7. | LF32H01004D4 | [1] | HOSE | KOB |
| 8. | LF32H01004D1 | [1] | HOSE | KOB |
| 9. | ZH22X08000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 9-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 10. | ZH32X08000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 10-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 11. | HH25X12012G4 | [1] | CONNECTION | KOB |
| 11-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 12. | ZH42X12000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOB45° -- 3/4" PF (Incls. O-Ring 237-6012) |
| 12-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 13. | ZH52X06000 | [1] | TEE,30 Degree Fl, Male, PF 3/8" x 3/8" x 3/8", O-Ring | KOB3/8"PFx54mm Long (Incls. O-Ring ZD12P01400) |
| 13-1. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 14. | HH55Q08008G3 | [1] | TEE,PF 1/2" x PF 1/2", O-Ring | KOB(PF 1/2) (Incls. O-Ring ZD12P01800) |
| 14-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 15. | ZH52X12000 | [1] | TEE,30 Degree Fl, Male, PF 3/4" x 3/4" x 3/4", O-Ring | KOB3/4"PFx76mm Long (Incls. O-Ring 237-6012) |
| 15-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 16. | 2414Z199D60 | [1] | PROTECTIVE SLEEVE | KOBHOSE |
| 17. | ZG15F03200 | [4] | COUPLING | KOB |
| 17-3. | ZG15G03200 | [2] | GASKET | KOB Superseded by part number: R44P0089D11S3 |
| 18. | ZG15F03800 | [1] | COUPLING | KOB |
| 18-3. | ZG15G03800 | [2] | GASKET | KOBGASKET Superseded by part number: R44P0089D1S3 |
| 19. | 2420T2948D1 | [4] | BOLT,M8 x 1.25 x 32mm W x 74mm L | KOBU -- M08x1.25x ID 32 x 74mm Long |
| 20. | ZN18C08007 | [16] | NUT | KOBM08x1.25mm |
| 21. | ZW16H08000 | [8] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 22. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 23. | ZS18C10060 | [1] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 24. | ZC27X32012 | [1] | CLAMP | KOB |
| 25. | 2436R576F3 | [1] | VALVE, CHECK | KOBASSY Superseded by part number: PW21V00003F1 |
| 26. | YT32H01031D5 | [1] | HOSE | KOBHOSE |
| 27. | YT32H01030P1 | [1] | BUSHING | KOB |
| 29. | PY01P01043D8 | [1] | CABLE TIE,102mm L | KOBWire Ties -- 368mm Long |
| 30. | YT32H01033P1 | [1] | RUBBER | KOB |
| 31. | YT32H01045P1 | [1] | BRACKET | KOB |
| 32. | ZS18C10030 | [1] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 33. | ZC46X29011 | [1] | CLIP | KOBClamp, Single Line -- ID 29 x 48mm Long |
| 34. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 35. | YT32H01021P1 | [1] | GROMMET | KOBGROMMET |
| 36. | 2418Z1333D27 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 600mm Length | KOBProtective Plastic |
| 38. | 2418Z1333D12 | [1] | PROTECTIVE SLEEVE,19.5mm ID x 23.8mm OD x 1500mm Length | KOBProtective Plastic |
| 39. | ZH32X06008 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 1/2", O-Ring | KOB90° -- 3/8"PFx1/2"PFx40mm Long (Same as ZD12P02400) |
| 39-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 40. | YT32H01016P1 | [1] | BUSHING | KOBBUSHING |
| 41. | ZH22X12000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P02400) |
| 41-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 42. | YT32H01046P1 | [1] | TUBE | KOB |
| 43. | YT32H01047P1 | [2] | CAP | KOB |
