| . . | YT06H00029F7 | [1] | CONTROL LINES, MAIN (STD) | |
| . . | YT06H00029FA | [1] | CONTROL LINES, MAIN (PIPING LESS) | |
| 1. | ZH32X04000 | [11] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), F7 Only |
| . . | ZH32X04000 | [9] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004), FA Only |
| 3. | ZH22X04000 | [16] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), F7 Only |
| . . | ZH22X04000 | [15] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100), FA Only |
| 4. | 2444T2524 | [4] | HYD CONNECTOR | KOB1/4" PF x 50mm Long (Incls. O-Ring ZD12P01100) |
| 6. | HH25R06004G2 | [1] | CONNECTION | KOB |
| 7. | 2444R1120D100 | [1] | HOSE | KOB1000mm Long (39-3/8 in) |
| 8. | 2444R1120D120 | [1] | HOSE | KOB1200mm Long (47-1/4in) |
| 9. | 2444R1120D070 | [1] | HOSE | KOB700mm Long (27-1/2 in) |
| 10. | 2444R1120D160 | [1] | HOSE | KOB1600mm Long (63 in) |
| 11. | 2420R349D075 | [2] | HOSE | KOB750mm Long (29-1/2 in) Superseded by part number: 2444R3019D3 |
| 12. | 2420R349D105 | [1] | HOSE,1050.00 mm | KOB1050mm Long (41-21/64 in) |
| 13. | 2420R349D090 | [2] | HOSE,6.35mm ID x 900mm L | KOB900mm Long (35-7/16 in) |
| 14. | 2444Z2525 | [5] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 15. | HH25R04004G3 | [1] | CONNECTION | KOB1/4"PFx72mm Long (Incls. O-Ring ZD12P01100) |
| 17. | PY01P01043D6 | [2] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 18. | ZH42X04000 | [3] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 19. | 2444Z2894 | [3] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 20. | ZH32X06000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 21. | ZH32X04006 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 22. | 2444R1120D045 | [1] | HOSE | KOB450mm Long (17-23/32 in) |
| 24. | LC52S00011P1 | [1] | SENSOR | KOBPressure (Low Pressure) (Incls. O-Ring ZD12P01100) Superseded by part number: LC52S00019P1 |
| 24-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 26. | 2444Z3541 | [1] | CONNECTION | KOB1/4" PF x 36mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 2444Z3759 |
| 27. | HH25X04004G3 | [1] | CONNECTION | KOB |
| 28. | HH55Q06004G3 | [1] | TEE | KOB |
| 29. | 2444R1120D090 | [2] | HOSE | KOB |
| 34. | YX64H01038P1 | [1] | ELBOW | KOB |
| 35. | 2444Z3802 | [1] | TEE | KOB |
| 36. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 37. | 2444R596D1 | [1] | 90 ELBOW | KOB90° -- 1/4" PF |
| 38. | 2444Z2461 | [6] | TEE | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 39. | 2444T3402 | [1] | TEE | KOBTee -- (Incls. O-Ring 237-6004) Superseded by part number: HH55V06006G3 |
