神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK70SR-1E/SK70SR-1ES ASN YT04-07001 (9/04-) (03-002) - NAME PLATE INSTAL (CAB) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
815 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT22T00055F4 | [1] | NAME PLATE INSTAL | |
| 20. | YB20T01013P1 | [1] | LABEL | KOB |
| 21. | YY20T01039P1 | [1] | LABEL | KOBDecal, Caution, Procedure to change selector valve… |
| 22. | PY20T01062P1 | [1] | CAUTION DECAL | KOBDecal, Caution - Attachment operation by foot pedal. Always check the … |
| . . | YT22T00055F5 | [1] | PLATE | KOB |
| 23. | YT20T01054P1 | [1] | LABEL | KOBDecal, Caution - Do not set this switch to nibbler combined flow operation … |
