神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK70SR-1E/SK70SR-1ES ASN YT04-07001 (9/04-) (02-002) - BOOM, HOE 3.72M (NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
347 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT02B00063F4 | [1] | ARM | KOBBOOM ASSY, HOE 3. 72M |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, HOE |
| 4-2. | HY35B10032G1 | [6] | BLOCK | KOB |
| 4-3. | YR02B01274P1 | [1] | BLOCK | KOB |
| 4-4. | YT02B01022P1 | [1] | PLATE | KOB |
| 4-5. | 2416T9878 | [1] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOB |
| 5. | LE02B01008P1 | [2] | BUSHING | KOB |
